Moving the Unpacked Chassis

The following figure shows a top view of the minimum aisle space required to install the Cisco NCS 6000
Series chassis without using the dolly supplied by Cisco. This space is exclusive of both the PDU brackets
(mounted on both sides), and the router cosmetics.
Figure 22: Minimum Aisle Space Requirements to Install the Cisco NCS 6000 Series Chassis — Top View (With Dolly
Removed)
1
2
3
Moving the Unpacked Chassis

Prerequisites

Before performing this task, make sure that the dolly is in the correct configuration, is firmly attached to the
unpacked chassis, and the dolly brakes are in the locked position.
Note If a dolly configuration change is required, see the
Cisco Network Convergence System 6000 Series Routers Unpacking, Moving, and Securing Guide
36
Chassis front
Chassis side
Moving space requirement: 34.7 in. (95 cm)
4 Chassis rear
5 Chassis side
Modifying the Dolly Configuration, on page
Moving the Chassis
11.
