-DRILL 10MM HOLE THROUGH FLOOR COVERING,
90MM DEEP USING PLATE AS A GUIDE.
-VACUUM OUT THE DUST.
-HAMMER SLEEVE ANCHOR DOWN INTO THE HOLE.
-TIGHTEN SLEEVE ANCHOR TO SPECIFIED TORQUE
USING 13MM SPANNER.
TIGHTEN ALL BOLT ASSEMBLIES WITHIN THE CIRCLE AS SHOWN TO SPECIFIED TORQUE. ENSURE
UPRIGHTS ARE PLUMB, DRILL AND SECURE ALL HOLES ON UPRIGHTS A SHOWN IN GUIDE.
SLEEVE ANCHOR BOLT FITTING
DRILL HOLE
90MM
30
Nm
VACUUM
HAMMER IN
BOLT
#MADEINBELFAST
30
Nm
TIGHTEN
