Tools Required - BLK BOX FREE STANDING COMPACT RIG GOLIATH Owner's Manual & Quick Start Manual

WARNING
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.

TOOLS REQUIRED

VACUUM
HAMMER DRILL
HAMMER
17MM SPANNER X2 10MM MASONRY
13MM SPANNER
No. Name
1 2.4 UPRIGHT
DNA60 WITH
FEET
1.2 SINGLE BAR
2
CM DNA60
3 0.4 BOX & BAR
CM DNA60
4 J-HOOK
PAIR
5 M10X80 SLEEVE
ANCHOR
6 M10X90 BOLT
7 M10 NYLOCK NUT
M10 FLAT
8
WASHER
STEP LADDER
SPIRIT LEVEL
DRILL BIT
SKU QTY
21-0036-0A 4
21-0015-0A
2
21-0009-0A 2
16-0001 1
10-0031 12
10-0008 24
10-0024 24
10-0016 60
PARTS & ATTACHMENTS
2
xx
Nm
1
3
4
5
6
7
8
#MADEINBELFAST
