Magtek ExpressCard 2000 Replacement Procedure page 12

3 - Power Supply Replacement Procedure
To re-install the power supply, follow these steps:
1) If the device is no longer positioned for access to the power supply screws:
a) Take appropriate steps to protect the work surface the EC2000 is on.
b) With a partner, safely and carefully move the EC2000's left side off the edge of the surface it sits
on, only until the four power supply screws on the bottom of the device are exposed (see Figure
3-2, Figure 3-3). Do not move the device any further off the edge than is absolutely necessary.
One person MUST hold the device at all times to keep it stable on the work surface.
2) Put the power supply back into the device and line up its screw holes with the four screw holes on the
bottom of the device.
3) Screw in and tighten the four screws.
4) Re-connect the output wires according to Figure 3-7.
5) Plug in the control and monitoring cable.
6) Re-connect the input wires. Insert the spade connectors behind the plate behind the screws (not
directly behind the screws). See Figure 3-5. The connections are as follows:
a) The green ground wire goes nearest the rear of the device.
b) The black wire goes in the middle.
c) The white wire goes nearest the front of the device.
7) Snap the clear plastic cover in place to cover the input wires.
8) With a partner, safely and carefully move the device back to a stable operating position.
9) Replace the left side access door (see 99875607 ExpressCard 2000 Hardware Service Manual for
detailed steps).
10) Perform any additional service that requires the device to be powered off and open.
11) Re-attach the power cable, network cable, and any security hardware.
12) Power up the device.
13) From the touchscreen, navigate to
functions properly and the sample looks correct. If the device does not power up or function
properly, contact MagTek Support Services.
ExpressCard 2000| Instant Issuance Card Personalization System | Power Supply Replacement Procedure
Page 12
> , create a sample card, and make sure the device
Menu Samples
