- Page 1 WALL UNIT 1000 Lift Assembly Guide 288 x 1000 360 x 1000 For Internal Use: FI.WR.INS.033_WKIN00122_WALL_1000_Lift_Extractor_Housing_Rev5.indd...
-
Page 2: Assembly Guide
WALL UNIT BEFORE YOU START 1000 Lift INSTALLATION Assembly Guide SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Muntin Frontal x1 Back Panel x2 End Panel x2 Base Panel (packed separately) HANGING BRACKET... - Page 3 WALL UNIT 1000 Lift Step 1. Assembly Guide Seat dowel (F) into holes in end panel (B) as Seat (G) shown. cam dowel into hole as shown. Step 2. Seat cam dowel (G) into holes in end panel (B) as Step 3.
- Page 4 WALL UNIT Step 6. 1000 Lift Seat dowel Assembly Guide (F) into holes in both panels (B) as shown. Seat (G) cam dowel into hole as shown. Step 7. Seat cam dowel (G) into holes in both end panels (B) as shown.
- Page 5 WALL UNIT 1000 Lift Assembly Guide Step 10. Join muntin panel (D) to both panels (C) using 4 x 45mm screws (P), through pilot holes provided. Step 11. Ensure carcass is square. Step 12. Slide the back panel clips (T) into the groove of both panels (B) &...
- Page 6 WALL UNIT 1000 Lift Assembly Guide Step 13. Hanging Brackets steps a,b & c to be carried out on both sides as shown Detail A Detail A Detail A Step a Step b Step c Insert Hanging Rotate locking Secure with provided Bracket into pre-drilled holes lever 180 degrees 2 x 20mm screws (S) per bracket...
- Page 7 WALL UNIT Step 16. Measure and attach Hinge Mounting Plate onto fixed shelf (C) as shown, 1000 Lift using screws which are already positioned within the Hinge Plates. Assembly Guide Left Right Front Front TOP FIXED SHELF Hinge Plates Front Front Step 17.
- Page 8 WALL UNIT Step 21. 1000 Lift Measure appropriately and attach the 2 x hanging bracket plates onto the wall screwing through the provided holes into your wall. Assembly Guide Screws for fixing to walls are not provided as these vary depending on your wall material and construction.
- Page 9 WALL UNIT Step 25. Clip hinges into hinge mounting 1000 Lift plates on the unit. Assembly Guide Step 26. Clip lift hinge mechanisms into each bracket. Step 27. Use a 4mm allen key to adjust the strength of the lift hinge for the door weight.
- Page 10 WALL UNIT 1000 Lift Assembly Guide...
- Page 11 WALL UNIT 1000 Lift Assembly Guide...
