- Page 1 WALL UNIT 1000 Lift Assembly Guide 288 x 1000 360 x 1000 For Internal Use: FI.WR.INS.033_WKIN00122_WALL_1000_Lift_Extractor_Housing_Rev8.indd...
- Page 2 WALL UNIT 1000 Lift Assembly Guide BEFORE YOU START INSTALLATION SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Muntin Frontal x1 Back Panel x2 End Panel x2 Base Panel (packed separately) HANGING...
- Page 3 Step 2. Step 3. Seat dowel (F) Seat cam dowel (G) into Seat (G) cam dowel into holes in holes in both end panels (B) into hole as both end panels (B) as shown. shown. as shown. Step 3. Attach panels x2 (C) to panel (B), using cam dowels (G) (in blue) and also using dowels (F) (in orange) in...
- Page 4 WALL UNIT 1000 Lift Assembly Guide Step 7. Step 6. Seat cam dowel Seat dowel (F) into holes in (G) into holes in both panels (B) as shown. both end panels (B) Seat (G) as shown. Cam Dowel into hole as shown.
- Page 5 Step 10. Join muntin panel (D) to both panels (C) using 4 x 45mm screws (P), through pilot holes provided. Step 11. Ensure unit is square. Step 12. Slide the back panel clips (T) into the groove of both panels (B) & (C).
- Page 6 WALL UNIT 1000 Lift Assembly Guide Step 13. Hanging Brackets steps a,b & c to be carried out on both sides as shown Detail A Detail A Detail A Step a Step b Step c Insert hanging Rotate locking Secure with provided bracket into pre-drilled holes lever 180 degrees 2 x 20mm screws (S) per bracket...
- Page 7 Hinge Plate 16. Hinge Plate. Using a 5mm Drill bit, drill into Top fixed shelf (C) using measurements as shown. Attach Hinge Mounting Plate onto top fixed shelf (C) using screws which are already positioned within the Hinge Plates. N.B. for Shaker 5 Piece Frontals, use 35mm measurement (M. 92mm 92mm Front...
- Page 8 WALL UNIT 1000 Lift Assembly Guide Step 17. Measure and attach lift hinge bracket with 2 x screws per bracket. The required screws are included inside lift hinge pack. Front Front 37mm 37mm Removed from lift hinge 160mm 160mm 192mm 192mm LEFT HAND RIGHT HAND...
- Page 9 Care to be taken. Hanging procedure is necessary for a safe installation. Screws for attaching to walls are not provided as these vary depending on materials, thickness and construction. Ensure appropriate fixings for wall construction are used. Step 21. Measure appropriately and attach the 2 x hanging bracket Hanging Bracket plates onto the wall screwing...
- Page 10 WALL UNIT 1000 Lift Assembly Guide Step 25. Clip hinges into hinge mounting plates on the unit. Step 26. Clip lift hinge mechanisms into each bracket. Step 27. Use a 4mm allen key to adjust the strength of the lift hinge for the frontal weight.
- Page 11 Page 10 For Internal Use: FI.WR.INS.033_WKIN00122_WALL_1000_Lift_Extractor_Housing_Rev8.indd...
