Start-up Operations
High viscosity products (maximum metering capacity: 15 l/h)
Set the jumper for capacity
use: High viscosity products (max. 1100 mPas) .
The longer suction stroke will take a reduced metering capacity.
Jumper Setting
Jumper left side
Metering capacity:
Infinitely variable from ... up to ... [l/h]
Suction stroke:
constantly [sec]
Pressure stroke:
Infinitely variable from ... up to ... [l/h]
Number of Strokes:
Infinitely variable from ... up to ... [l/h]
Max. Metering counterpressure:
[MPas (bar)]
Reduced metering rate (maximum metering capacity: 2.6 l/h)
If you are removing the jumper for capacity (
Pos. J2) the maximum pump metering rate will reduced if you are metering capacities
lower than 2.6 l/h..
The metering capacity can set precise at the potentiometer (
flow rate' on page 33) between 0.1 (min.) and 2.6 l/h (max.).
The longer suction stroke in this setting allow the metering from: lower viscosity products
and also high viscosity products.
Jumper Setting
Without Jumper
Metering capacity:
Infinitely variable from ... up to ... [l/h]
Suction stroke:
constantly [sec]
Pressure stroke:
Infinitely variable from ... up to ... [l/h]
Number of Strokes:
Infinitely variable from ... up to ... [l/h]
Max. Metering counterpressure:
[MPas (bar)]
Rev. 5-06.2018
Ä Chapter 4.1.2 'Pump module' on page 22, pos. J2) if you
Metering Volume Setting - Potentiometer Setting
Minimum
Ä Chapter 4.1.2 'Pump module' on page 22,
Metering Volume Setting - Potentiometer Setting
Minimum
66,4
32
1
0,225
6,4
9
0,2 (2)
Ä Chapter 6.1.1 'Setting the
0,1
0,225
0,9
0,2 (2)
Maximum
15
0,18
135
Maximum
2,6
2
27
