Summary of Contents for Adam Equipment PTS plus Series

  • Page 1 Adam Equipment       PTS plus   Software rev: V 1.00 & above       ...
  • Page 2           Easy Reference:      Model name of the scale: Serial number of the unit: Software revision number (Displayed when power is first turned on): Date of Purchase: Name of the supplier and place:                ...
  • Page 4: Table Of Contents

      CONTENTS P.N. 3.10.6.6.15393, Rev A, November 2019 PTS PLUS SPECIFICATION ......................... 1     SAFETY ..............................1     INSTALLATION ............................. 5     AE403 ASSEMBLY ..........................6     CALIBRATION ............................9     TROUBLE SHOOTING ........................10  ...
  • Page 5: Pts Plus Specification

        PTS PLUS SPECIFICATION   Model PTSplus 2000 PTSplus 5000a Load cell Capacity 2000 kg 5000 Lb Resolution 0.5 kg Readability 0.5kg 1lb /0.5kg Repeatability (sd) 2lb / 1kg Linearity 2lb / 1kg Fork length 1150mm (45.25“) 48” (1220mm) Fork Width (each) 160mm (6.3”) 6.3”...
  • Page 6        Check the pallet truck first before using it making sure that the wheels, handles and forks are fitted correctly and secure  Avoid unsuitable and uneven floor surfaces  Please wear protective clothing where necessary  Allow 60cm clearance from the pallet truck when operating. ...
  • Page 7        ...
  • Page 8        ...
  • Page 9: Installation

      INSTALLATION   Please follow the installation instructions to ensure correct operation of your PTS plus. In transportation the handle is removed from the truck, this needs to be installed following the instructions below: NOTE: Do not lower the handle down fully until completing the instructions below. 1) Insert the roller pin into the hole of roller rack, securing the handle to the frame 2) Fit the split pin through the holes provided.
  • Page 10: Ae403 Assembly

        AE403 ASSEMBLY                   Rear view of AE 403 Indicator Fit AE403 load cell connecting cable according to the picture below:   AE 403 indicator connecting        Fit 7pin connector here; plug must tight to seal it up and also prevent from getting loose, otherwise, it will affect weighing.
  • Page 11           AE403 drive pipe Indicator box     4pcs of M6X40 socket head cap screws             Fit the indicator box with 4pcs of M5 socket head cap screws, 4pcs of M5 spacers, 4pcs of M5 flat gaskets and fix it tight with 4# Allen key.
  • Page 12   M5 spacer M5 flat gasket M5X18 socket head cap screw       Fit AE403 load cell cable 5pin connector to the scale according to the picture below. Fit AE403 load cell cable 5pin connector to the scale...
  • Page 13: Calibration

      Load cell connecting definition (5pin aviation waterproof connector), see the area in the circle:     1pin:(E+)red cable 2pin:(E-)black cable 3pin:(SH)shield cable 4pin:(S+)green cable 5pin:(S-)white cable   CALIBRATION The PTS plus is factory calibrated, if further information is required for re-calibrating the scale the procedure is as follows: ...
  • Page 14: Trouble Shooting

       After pressing [Tare] ↵, ‘noload’ should appear on the display. Use the directional button ⭡ to switch to ‘load1’ and set the desired weight limit of the test object to be placed on the scale using the ⭡ or ⭣ directional buttons and the ⭢...
  • Page 15: Maintenance

        MAINTENANCE  Please check the oil every six months , we suggest you use hydraulic oil: ISO VG32  Whilst in transit air may enter into the hydraulic pump, this may result in the forks not raising when first used. Please move the handle up and down several times to allow air to escape.
  • Page 16: Service Information

              SERVICE INFORMATION This manual covers the details of operation. If you have a problem with the scale that is not directly addressed by this manual then contact your supplier for assistance. In order to provide further assistance, the supplier will need the following information which should be kept ready:  ...
  • Page 17: Warranty Statement

          WARRANTY STATEMENT Adam  Equipment  offers  Limited  Warranty  (Parts  and  Labour)  for  any  components  that  fail  due to defects in materials or workmanship. Warranty starts from the date of delivery.    During the warranty period, should any repairs be necessary, the purchaser must inform its  supplier  or  Adam  Equipment  Company.  The  company  or  its  authorised  Technician  reserves  the right to repair or replace the components at any of its workshops at no additional cost,  depending  on  the  severity  of  the  problems.  However,  any  freight  involved  in  sending  the  faulty units or parts to the Service Centre should be borne by the purchaser. ...
  • Page 18   WEEE 2012/19/EU    This device may not be disposed of in domestic waste. This also applies to countries outside the  EU, per their specific requirements. Disposal of batteries (if fitted) must conform to local laws  and restrictions.  Cet appareil ne peut être éliminé avec les déchets ménagers. L’élimination de la batterie doit  être effectuée conformément aux lois et restrictions locales.  Dieses Gerät nicht mit dem Hausmüll entsorgt.  Dispositivo no puede ser desechado junto con los residuos domésticos  Dispositivo non può essere smaltito nei rifiuti domestici.    FCC / IC CLASS A DIGITAL DEVICE EMC VERIFICATION STATEMENT  NOTE: This equipment has been tested and found to comply with the limits for a Class A digital  device, pursuant to Part 15 of the FCC rules and Canadian ICES‐003/NMB‐003 regulation. These  limits  are  designed  to  provide  reasonable  protection  against  harmful  interference  when  the  equipment is operated in a commercial environment.  This equipment generates, uses and can  radiate radio frequency energy and, if not installed and used in accordance with the instruction  manual,  may  cause  harmful  interference  to  radio  communications.    Operation  of  this  equipment ...
  • Page 19  ...
  • Page 20       ADAM EQUIPMENT is an ISO 9001:2015 certified global company with more than 40 years’ experience in  the production and sale of electronic weighing equipment.    Adam products are predominantly designed for the Laboratory, Educational, Health and Fitness, Retail and  Industrial Segments. The product range can be described as follows:    ‐Analytical and Precision Laboratory Balances  ‐Compact and Portable Balances  ‐High Capacity Balances  ‐Moisture analysers / balances  ‐Mechanical Scales   ‐Counting Scales  ‐Digital Weighing/Check‐weighing Scales  ‐High performance Platform Scales   ‐Crane scales  ‐Mechanical and Digital Electronic Health and Fitness Scales  ‐Retail Scales for Price computing  For a complete listing of all Adam products visit our website at  www.adamequipment.com          Adam Equipment Co. Ltd.  Adam Equipment Inc.  AE Adam GmbH.  Maidstone Road, Kingston  1, Fox Hollow Rd.  Instenkamp 4  Milton Keynes  Oxford, CT 06478  D‐24242 Felde  MK10 0BD      UK  USA  Germany ...
