  • Page 1 Adam Equipment AZextra SERIES (with EC type Approval) (P.N. 6315, Rev. D, August 2017) Software rev.: 2.29A & above © Adam Equipment Company 2017...
  • Page 2 © Adam Equipment Company 2017...
  • Page 3: Table Of Contents

    RS-232 Setup ..................... 133 3.11 REAL TIME CLOCK SETUP ................155 ERROR CODES ....................166 CALIBRATION ...................... 177 CALIBRATION PROCEDURE ................177 REPLACEMENT PARTS AND ACCESSORIES ........... 177 SERVICE INFORMATION ..................188 © Adam Equipment Company 2017 1 of 22...
  • Page 4: Introduction

    • Real Time Clock (RTC) and date • RS-232 bi-directional interface • Battery operated for portability • 90 hours battery life when fully charged • Up to 103 Prices (PLU) stored for easy access © Adam Equipment Company 2017 2 of 22...
  • Page 5: Specifications

    Avoid air movement such as from fans or opening doors. Do not place near open windows or air-conditioning vents. • Keep the scales clean. Do not stack material on the scales when they are not in use. © Adam Equipment Company 2017 3 of 22...
  • Page 6: Setting Up The Scales

    • The unit will display the software revision number in the Weight window and count down to zero while performing a self-test. • When ready all three displays will show zero. DISPLAY WINDOWS Not applicable for South Africa and Far East © Adam Equipment Company 2017 4 of 22...
  • Page 7: Battery Charging

    • If the battery has not been used properly or it is used for a number of years it may eventually fail to hold a full charge. If the battery life becomes unacceptable then contact your distributor or Adam Equipment. © Adam Equipment Company 2017 5 of 22...
  • Page 8: Key Descriptions

    It selects the unit price per kilogram or per 100g. NOTE: For South Africa and Far East, unit price per 100g or per kg is not available. [Print] key It sends the results of the current displays to the RS-232 interface. © Adam Equipment Company 2017 6 of 22...
  • Page 9: Operation

    • When the product and container are removed the weight window will show a negative value. If a different container is to be used, remove this negative tare value by pressing the [Tare] once more. © Adam Equipment Company 2017 7 of 22...
  • Page 10: Determining Value Of A Product By Weight

    100g of a particular item very easily using the PLU values. NOTE: For South Africa and Far East, unit price per 100g or per kg is not available. © Adam Equipment Company 2017 8 of 22...
  • Page 11 If the item is loaded on the pan, the Total Price window will show the total cost. If nothing is loaded, only the PLU value saved for the location will be displayed in the Unit Price window and the Total Price window will display “0,00 ”. © Adam Equipment Company 2017 9 of 22...
  • Page 12: Entering Values For The Plu S

    For example, press [1] and [4] for the position 14. It will show “PLU” “14” “SAVEd ” before returning to weighing. • To change the earlier saved value against a particular PLU, simply repeat the process. © Adam Equipment Company 2017 10 of 22...
  • Page 13: Price Per Kilogram And Per 100 Gram- [Kg 100G] Key

    • This information is also saved for the PLU values that are stored in the memory. NOTE: This is not applicable for AZextra for South Africa and Far East. © Adam Equipment Company 2017 11 of 22...
  • Page 14 • It will be on when a weight is on the platform or when a key is pressed. • It will turn off automatically after a few seconds when the weight is zero or after a while, the last key was pressed. © Adam Equipment Company 2017 12 of 22...
  • Page 15: Input Commands Format

    [Print] key for 4 seconds to access the parameters. Press [Print] to scroll through the options and [Tare] to confirm the change and then advance to the next parameter. When a parameter is entered by pressing [Tare], the © Adam Equipment Company 2017 13 of 22...
  • Page 16 UNIT PRICE TOTAL ------------------------------------- £ 1.20/100g 0.200kg £ 2.40 Label 2 (Spanish with $ shown): FECHA 2017/04/08 HORA 04:00:30 PRECIO UNIT. $ 10.99/100g NETO 0.200kg TOTAL $ 21.98 Label 3 (Weight only): 0.200kg © Adam Equipment Company 2017 14 of 22...
  • Page 17: Real Time Clock Setup

    An error code will be shown if the time (Err 1) or the date (Err 2) is not the permissible values. For example, 34 day of a month is an invalid entry. © Adam Equipment Company 2017 15 of 22...
  • Page 18: Error Codes

    Improper calibration of the pressed, scale. Damaged load cell. Damaged Electronics. A/D count is not correct Platform is not installed. Err 6 when turning the scale Load cell is damaged. Electronics is damaged. © Adam Equipment Company 2017 16 of 22...
  • Page 19: Calibration

    STANDARDS OFFICE FOR FURTHER ASSISTANCE. 6.0 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier or Adam Equipment. A partial list of such items is as follows- • Main Power cord • In use cover •...
  • Page 20: Service Information

    Include any recent history of the unit. For example: -Has it been working since it’s delivered -Has it been in contact with water -Damaged from a fire -Electrical Storms in the area -Dropped on the floor, etc. © Adam Equipment Company 2017 18 of 22...
  • Page 21 This product may include a rechargeable battery that is designed to be removed and replaced by the user. Adam Equipment warrants that it will provide a replacement battery if the battery manifests a defect in materials or workmanship during the initial period of use of the product in which the battery is installed.
  • Page 22 WARNING: This product includes a sealed lead-acid battery which contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Adam Equipment products have been tested with, and are always supplied with mains power adaptors which meet all legal requirements for the intended country or region of operation, including electrical safety, interference and energy efficiency.
  • Page 23 © Adam Equipment Company 2017 21 of 22...
  • Page 24 © Copyright by Adam Equipment Co. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
