(P.N. 3056610542, Revision C2, July 2013)
Adam Equipment strives to be more environmentally focused and uses recycled materials and
environmentally friendly packaging where possible. As part of this initiative we have developed a short
manual that uses less paper and ink to describe the main functions of your new Adam indicator/scale. A
complete version is available at www.adamequipment.com. Thank you for your support of Adam Equipment
and we hope that you enjoy your new scale.
GK / GBK / GFK SCALE
Adam Equipment
© Adam Equipment Company 2013
Advertisement
Table of Contents
Related Manuals for Adam Equipment GK series
Summary of Contents for Adam Equipment GK series
- Page 1 Adam indicator/scale. A complete version is available at www.adamequipment.com. Thank you for your support of Adam Equipment and we hope that you enjoy your new scale.
- Page 2 © Adam Equipment Company 2013...
-
Page 3: Table Of Contents
ACCUMULATED TOTAL ..............8 RS-232 SPECIFICATION ..............9 CALIBRATION ..................10 CALIBRATION COUNTER FOR APPROVED SCALES ....10 SPECIFICATIONS ................11 ERROR MESSAGES ................16 MENU STRUCTURE ................17 WARRANTY INFORMATION ............. 18 P a g e © Adam Equipment Company 2013... - Page 4 P a g e © Adam Equipment Company 2013...
-
Page 5: Setting Up And Turning On The Scales
Press [Tare] or [Zero] to remove the tare value and display zero. The indicator will disappear. P a g e © Adam Equipment Company 2013... -
Page 6: Parts Counting
NOTE: If the parts are too light to measure accurately, the count may become faulty. It is suggested that the . samples to be weighed should each weigh more than the resolution of the indicator P a g e © Adam Equipment Company 2013... -
Page 7: Check-Weighing
2 seconds indicating the location X where the current limits, weighing units and settings for the beeper and bar graph are stored. The indicator will continue to work with the current settings as active. P a g e © Adam Equipment Company 2013... -
Page 8: Percent Weighing
The display may jump by large numbers unexpectedly if small weights are used to set as 100% reference. Error 7 The indicator checks if the weight is too small and will show P a g e © Adam Equipment Company 2013... -
Page 9: Animal (Dynamic) Weighing
.Remove the animal, the display will hold the weight value. “Ani” Press the [Unit] key to unlock the display. The display will flash twice, and be ready for the next animal. Press [zero] key to return to normal weighing. P a g e © Adam Equipment Company 2013... -
Page 10: Accumulated Total
Adding a 2nd weight will repeat the process. While the weight is on the platform, press the [Print] key to view the values- first the accumulation number "ACC x" and then the total will be shown. P a g e © Adam Equipment Company 2013... -
Page 11: Rs-232 Specification
RS-232 output of weighing data ASCII code 9600 Baud (user selectable) 8 data bits No Parity Connector: 9 pin d-sub miniature socket Pin 3 Output Pin 2 Input Pin 5 Signal Ground P a g e © Adam Equipment Company 2013... -
Page 12: Calibration
Enter calibration or “P1000” to enter the parameters, followed by pressing the [Tare] key. The Calibration access will allow user calibration and the parameter code will allow access to the following parameters. P a g e © Adam Equipment Company 2013... -
Page 13: Specifications
Weighing, Check Weighing, Parts counting, check‐counting, , Animal Weighing, Accumulating memory, Interface RS‐232 bi‐directional interface English, German, French, Spanish selectable text Note: For approved indicators the input specifications is limited to 1.5 µv per division and the number of divisions is limited to 3000d. Kilograms only. P a g e © Adam Equipment Company 2013... - Page 14 400mm x 620mm x 400mm x 620mm x 600 mm x 940 mm x 400mm x 620mm x 400mm x 620mm x (w x d x h) 860mm / 15.7” x 860mm / 15.7” x 860mm / 15.7” x 900 mm 860mm / 15.7” x 860mm / 15.7” x 24.4” x 33.9” 24.4” x 33.9” 24.4” x 33.9” 23.6” x 37” x 35.4” 24.4” x 33.9” 24.4” x 33.9” Net Weight 12.5kg / 27.6 Lb 12.5kg / 27.6 Lb 12.5kg / 27.6 Lb 25.5 kg / 56.2 Lb 12.5kg / 27.6 Lb 12.5kg / 27.6 Lb Features Weighing/Counting/Checkweighing with LED lights/Percentage/Hold function/RS232 P a g e © Adam Equipment Company 2013...
- Page 15 Kilograms and pounds, grams for all except GFK120/260a only, XXXa also to have pounds, Ounces, & Pound/Ounces Stabilization Time 2‐3 Secs Operating Temperature ‐10°C to +40°C / +14°F to +104°F Power Supply 230VAC 50/60Hz. in Europe, Asia and South Africa. 12vDC 800mA UL/CSA adapter for USA Calibration External Calibration Mass User Selectable Display Backlit Green display 20mm with capacity tracker Balance Housing Cast aluminum base, Pantone cool grey painted base, stainless steel grade 304 Top pan, ABS Cool grey indicator housing Pan Size 300mm x 400mm x 50mm / 11.8” x 15.7” x 2” Overal Dimensions 300mmx 520mm x 660mm / 11.8” x 20.5” x 26” (w x d x h) Net Weight 7.6kg / 16.8 Lb Features Weighing/Counting/Checkweighing with LED lights/Percentage/Hold function/RS232 P a g e © Adam Equipment Company 2013...
- Page 16 0.05kg 0.1kg Units of Measure Kilograms only Stabilization Time 2‐3 Secs ‐10°C to +40°C / +14°F to +104°F Operating Temperature 230VAC 50/60Hz. Power Supply External Calibration User Selectable Calibration Mass Backlit Green display 25mm with capacity tracker Display Cast Aluminum base, Pantone cool grey painted base, stainless steel grade 304 Top pan, ABS Cool grey indicator housing Balance Housing 400mm x 500mm Pan Size 15.7” x 19.7” Overal Dimensions 400 mm x 620 mm x 860 mm (w x d x h) 15.7” x 24.4” x 33.9” 12.5kg / 27.6 Lb Net Weight Weighing/Counting/Checkweighing with LED lights/Percentage/Hold function/RS232 Features P a g e © Adam Equipment Company 2013...
- Page 17 Cast Aluminum base, Pantone cool grey painted base, stainless steel grade 304 Top pan, ABS Cool grey indicator Balance Housing housing Pan Size 300mm x 400mm x 50mm / 11.8” x 15.5” x 2” Overal Dimensions 300mmx 520mm x 660mm / 11.8” x 20.5” x 26” (w x d x h) 7.6kg / 16.8 Lb Net Weight Weighing/Counting/Checkweighing with LED lights/Percentage/Hold function/RS232 Features P a g e © Adam Equipment Company 2013...
-
Page 18: Error Messages
FAIL H or Calibration error Improper calibration (should be within +10% of the factory calibration). The old calibration data FAIL L will be retained until the calibration process is complete. P a g e © Adam Equipment Company 2013... -
Page 19: Menu Structure
C6 Uid Enter using numeric keys FASt F5 NCk User ID Negative Check S7 SPS Enter using numeric weighing Off C7 Sid Enter using numeric keys Scale password keys Scale ID C8 LAb LAb On S8 CAL Perform calibration Lab Off 17 | P a g e © Adam Equipment Company 2013... -
Page 20: Warranty Information
Repairs carried out under the warranty does not extend the warranty period. Components removed during the warranty repairs become the company property. The statutory right of the purchaser is not affected by this warranty. The terms of this warranty is governed by the UK law. For complete details on Warranty Information, see the terms and conditions of sale available on our web‐site. 18 | P a g e © Adam Equipment Company 2013... - Page 21 19 | P a g e © Adam Equipment Company 2013...
- Page 22 As we often update adaptor products to meet changing legislation it is not possible to refer to the exact model in this manual. Please contact us if you need specifications or safety information for your particular item. Do not attempt to connect or use an adaptor not supplied by us. © Adam Equipment Company 2013...
- Page 23 © Copyright by Adam Equipment Co. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice. All information contained within this publication is to the best of our knowledge timely, complete and accurate when issued. However, we are not responsible for misinterpretations which may result from the reading of this material. The latest version of this publication can be found on our Website. www.adamequipment.com © Adam Equipment Company 2013...
