Page 2
1 Functions and features The through-beam sensor detects objects and materials without contact and indicates their presence by a switching signal. For the range see the type label. 2 Installation ► Install the receiver (OGE08x) and secure it to a bracket. ► Align the transmitter (OGS08x) to the receiver and secure it also to a bracket. >...
Page 3
3.2 Receiver 4 Operation Check whether the sensor operates correctly. • Receiver (OGE08x): The yellow LED is lit when the switching output is swit- ched. • Transmitter (OGS08x): The green LED is lit when the sensor is ready for operation. 5 ...
