- Page 1 Operating instructions Through-beam sensor OGE3xx / OGS3xx...
-
Page 2: Symbols Used
1 Preliminary note 1.1 Symbols used ► Instruction > Reaction, result → Cross-reference Important note Non-compliance can result in malfunctions or interference. 2 Functions and features The through-beam sensor detects objects and materials without contact and indicates their presence by a switching signal. Range: (→... - Page 3 Transmitter (OGS3xx) connector pin 1 = L+ (pin 2: not connected) pin 3 = L- (pin 4: not connected) Transmitter (OGS3xx) cable * BN = L+ BU = L- Receiver (OGE3xx) connector pin 1 = L+ (pin 2 = not connected) pin 3 = L- pin 4 = load Receiver (OGE3xx) cable *...
- Page 4 Keep the front lenses of the sensor free from soiling. ► For cleaning do not use any solvents or cleaning agents which could damage the plastic material. Technical data and further information at www.ifm.com → Select your country → Data sheet direct:...
