Tube Replacement Chart - StewMac ’64 REVERB UNIT Assembly Instructions Manual

Cut this label on the dotted line with a razor knife and metal straightedge .
Fasten it to the bottom of the cabinet using thinned wood glue or contact cement .
stewmac.com
StewMac
®
I C O N K I T S
DANGER: Unplug the unit before changing tubes.
Tube locations from left to right:
6V6
V3
#10733
The duplicate copy is included as a backup .
StewMac
®
I C O N K I T S
DANGER: Unplug the unit before changing tubes.
Tube locations from left to right:
6V6
V3
#10733
'64 REVERB UNIT
O R I G I N A L 6G 1 5 C I R C U I T
12AT7 12AX7
(ECC81) (ECC83)
V2 V1
Use only 1-amp slow-blow fuse.
'64 REVERB UNIT
O R I G I N A L 6G 1 5 C I R C U I T
12AT7 12AX7
(ECC81) (ECC83)
V2 V1
Use only 1-amp slow-blow fuse.
39
© 2018 StewMac
