INSTALLATION AND OPERATION INSTRUCTIONS FOR
TRD-26
TRD-30
TRD-33
TRD-38
TRD-44
TRD-48
SAFETY INFORMATION
WARNING
For your safety, always comply with all
warnings and safety instructions
contained in this manual to prevent
personal injury or property damage.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this appliance.
INSTALLER: LEAVE OWNER'S MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN OWNER'S MANUAL FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amantii TRD-26
Summary of Contents for Amantii TRD-26
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS FOR TRD-26 TRD-30 TRD-33 TRD-38 TRD-44 TRD-48 SAFETY INFORMATION WARNING For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this appliance.
-
Page 2: Table Of Contents
Please read and carefully follow all of the instruction found in this manual. Please pay special attention to the safety instructions provided in this manual. The instructions included here will assure that you have many years of dependable and enjoyable service from your Amantii product. Table of Contents IMPORTANT INSTRUCTIONS .......................... -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE RETAIN THIS USER GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1) Read all instructions before using this fireplace 2) The fireplace is hot when in use. -
Page 4: Unpacking And Testing Appliance
UNPACKING AND TESTING APPLIANCE Carefully remove the appliance from the box. Prior to installing the appliance, test to make sure the appliance operates properly by plugging the power supply cord into a conveniently located 120 Volt grounded outlet. Test all aspects of its operation (manual switches, remote and heater) to make sure all components operate correctly. -
Page 5: Trd-26
TRD - 26 Description This appliance has been tested in ELECTRIC FIREPLACE accordance with the UL Standard 2021 Voltage 120V AC 60Hz for fixed and location dedicated Watts 1200W Max electric room appliances in the United NO HEATER States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 6: Trd-30
TRD - 30 Description This appliance has been tested in ELECTRIC FIREPLACE Voltage 120V AC 60Hz accordance with the UL Standard 2021 for fixed and location dedicated Watts 1200W Max electric room appliances in the United NO HEATER States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 7: Trd-33
TRD - 33 Description This appliance has been tested in ELECTRIC FIREPLACE Voltage 120V AC 60Hz accordance with the UL Standard 2021 for fixed and location dedicated Watts 1200W Max electric room appliances in the United NO HEATER States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 8: Trd-38
TRD - 38 Description This appliance has been tested in ELECTRIC FIREPLACE Voltage 120V AC 60Hz accordance with the UL Standard 2021 for fixed and location dedicated Watts 1200W Max electric room appliances in the United NO HEATER States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 9: Trd-44
TRD - 44 Description This appliance has been tested in ELECTRIC FIREPLACE Voltage 120V AC 60Hz accordance with the UL Standard 2021 for fixed and location dedicated Watts 1200W Max electric room appliances in the United NO HEATER States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 10: Trd-48
TRD - 48 Description This appliance has been tested in ELECTRIC FIREPLACE Voltage 120V AC 60Hz accordance with the UL Standard 2021 for fixed and location dedicated Watts 1200W Max electric room appliances in the United NO HEATER States and Canada. If you need MOTOR HEATER assistance during installation, please Appliance Width... -
Page 11: Installation Built-In
OUTDOOR INSTALLATIONS The TRD series electric fireplaces are suitable for installation in outdoor areas protected from direct water impingement. In addition to maintaining the listed mantel and combustibles clearances, a rain protection overhang factor of 1/2 shall be constructed to the front and to each side of the installed appliance. -
Page 12: Installation Outdoor
120 Volt grounded outlet. The rough wall opening size of the of the fireplace: W(“) D(“) H(“) TRD-26 26 1/4 12 3/8 16 27/32 TRD-30 30 3/8 12 3/8 19 7/32 TRD-33... - Page 13 2. When the trim is removed, take , take off the front glass panel. 3. Unscrew the screws located on ed on each side and take off the inner side stee e steel panels. Inner side panels...
- Page 14 4. Put the trim back onto the applia appliance and fasten with screws.(NOTE: This : This step is to make sure that the fireplace fits the wa the wall opening well and there is no gap betw between the trim and the wall after installation) 5.
- Page 15 6. Remove the trim following STEP STEP 1. Screw back the inner side steel pane l panels. 7. Put back the front glass panel a el and screw back the trim after you finish th ish the media decoration.
-
Page 16: Hard- Wire Installation
HARD- WIRE INSTALLATION Turn off the appliance completely a ely and let cool before servicing. Only a qualified ified technician should service and repair this electr lectric appliance. If it is necessary to hard wire this ap is appliance, a qualified electrician must remove ualified electrician must remove the cord connection and wire the appliance directly to t ire the appliance directly to the household wiring . -
Page 17: Media Options
MEDIA OPTIONS Your fireplace ships with a 10 piece Birch Log Set, Charcoal Grey Real Fireglass, one (1) bag of Black Vermiculite and one (1) bag of White Vermiculite. CHARCOAL GREY REAL VERMICULITE FIREGLASS 10-PIECE BIRCH LOG SET MEDIA INSTALLATION Unscrew 4 screws and take off the trim. -
Page 18: Operation
OPERATION The fireplace can be operated ei ted either by the touch panel located on the lef the left front top side of the fireplace, or by supplied remo d remote control. Plug the fireplace into a 15 Amp Amp wall socket. MANUAL OPERATION 1. -
Page 19: Remote Control Operation
REMOTE CONTROL OPERATION For remote to function make sure the heater is plugged in and the main power switch located on the bottom left hand side is at position I. Important: When operating the remote make sure you point the remote to the center of the fireplace each time you press the button. -
Page 20: Installing Wall Thermostat
INSTALLING WALL THERMOSTAT WALL THERMOSTAT WIRING DIAGRAMS Wire the wall thermostat prior to installing the fireplace. WALL THERMOSTAT WIRING (24 VAC) Install Wall Thermostat per instructions provided with kit and per the following information: 1. Turn off circuit breaker. 2. Remove cover plate located on the left side of appliance. Pull the wire out and cut the inside thermostat. -
Page 21: Replacement Parts
REPLACEMENT PARTS This list contains replacement parts PART NUMBER DESCRIPTION TRD-26 TRD-30 TRD-33 10702245 10702247 10702249 BOTTOM GLASS 10701375 10701376 10701377 FRONT CLEAR GLASS 3215501 3216501 3217501 TRIM SIDE STEEL PANEL 10702244 10702246 10702248 BACK GLASS 301506 REMOTE RECEIVER 601094H... - Page 22 This list contains replacement parts PART NUMBER DESCRIPTION TRD-38 TRD-44 TRD-48 10702251 10702253 10702255 BOTTOM GLASS 10701378 10701379 10701380 FRONT CLEAR GLASS 3218501 3219501 3220501 TRIM SIDE STEEL PANEL 10702250 10702252 10702254 BACK GLASS 301506 REMOTE RECEIVER 601095D CIRCUIT BOARD 602130B BLOWER AND HEATER ASSEMBLY...
-
Page 23: Exploded View
EXPLODED VIEW... -
Page 24: Troubleshooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Dim or no flame Flame LED’s are burnt out. Inspect the LED’s and replace them if necessary. Back black cloth is falling off Change a flicker and back black cloth. and rolled up in the flicker. Ember Ember LED’s are burnt out Inspect the ember bed LED’s and... -
Page 25: Service History
SERVICE HISTORY This heater must be serviced annually depending on usage. Date Dealer Service technician Service Performed Special Concerns Name Name NOTES:... -
Page 26: Warranty
Amantii warrants such products to be free from defects in material and workmanship for a period of two (2) years from the date of the first purchase of such products. The limited two (2) year warranty period for products also applies to any implied warranties that may exist under applicable law. Some...
