1.1 Attributes

• Overload protection on each channel
• Possibility to connect up to 2 receivers with serial interface
(PPM, EX Bus)
• Built-in Expander function for up to 3 sensors
• Input for magnetic switch or RC switch (Central Box 200 only)
• MPX battery input connector(s):
1x Central Box 100, 2x Central Box 200
• 100Hz mode of servo outputs (10ms period)
• Supports EX telemetry (voltage, current, capacity, and
temperature measurement, overload indication, ...)
• Easy settings changes via DC/DS transmitter
• Firmware updates by user
• Suitable for use with high voltage (HV) servos
• Compact size for easy installation
• Each output is individually configurable (channel assignment,
trim, reverse, ATV)

2 Description

2.1 Central Box 200

Central Box 200 has 15 outputs for servos with overload
protection.
Channels 14 and 15 are configurable as:
• servo output
• an input for telemetry sensor
Ext1 port can be configured for use as:
• an output to connect a JETIBOX or Duplex EX receiver to
either configure the Central Box or for the output of
telemetry data
• an input for telemetry sensors
