• FS position – setup of the selected output deflection in case of
signal loss
• FS speed – setup for how quickly the output transitions to its
programmed deflection in case of signal loss
• ATV High Limit Yx – sets the upper travel (throw) limit of the
output
• ATV Low Limit Yx – sets the lower travel (throw) limit of the
output
• Output Trim – setting the neutral deflection of the receiver
output
• Output Group – setting the output to a selected group of output
pulses that will be generated from the receiver at the same time

4.5 Alarms

*CENTRAL BOX*: Alarms – pushing the D button (down arrow)
moves you to the menu for setting the alarms. If the alarm is set to
OFF, the alarm is deactivated.
• Capacity Alarm - level of the capacity taken from the battery at
which the alarm will sound
• Current Alarm - level of current drawn from the battery at which
the alarm will sound
• Voltage Alarm – if the battery voltage drops below this level, the
alarm will sound
• Short Circuit Alarm - Activating/deactivating the alarm for when
the outputs are overloaded
• Temperature Alarm – Activating/deactivating alarms for the
Central Box overheating
