4 Configuration via JETIBOX

The JETIBOX terminal can be used for parameter setting and
retrieving data. After connecting to the Central Box (output Ext1), a
startup screen appears that contains identification of the device in
the first line of the JETIBOX display. The second line contains the
data showing the consumed capacity of batteries 1 and 2.
By pushing the R button (to the right) on the JETIBOX, you get to the
expander menu.
In the expander menu, the second lines display the sensors that are
connected to inputs Ext1, Ext2/15 and Ext3/14.
Using buttons U and D (down and up arrows) of the JETIBOX it is
possible to browse through the expander inputs. The selected
input is marked with a curly bracket brace after the input number,
eg. 1}. By pushing the R button (right arrow) it is possible to enter a
selected sensor, where you can adjust and display its parameters.
Return from the sensor menu:
- by holding the L button (left arrow) for extended time
- by holding the L button (left arrow) for short time, in
case you are in the basic menu of the sensor (in the first line there is
identification of the sensor and in the second line there are actual
data, such as „MUI 30; 14,2V 7,8A")
The input marked 1}... means that there is no device connected to
this input or the connected device is not compatible, or the input
from the Central Box is not properly configured.
By pushing the D button (down), you get from the initial screen of
the Central Box to its menu.
