Setting Up Your Computer System
Figure 2-2 Graphic Monitor Power Switch
Color monitor
Monitor
power
cord
Local ac
power outlet
Computer
power
cord
Figure 2-3 Plugging the Cables and Power Cord into the Monitor and Computer Unit
2-4
R, G/MONO, and B
connectors
Color monitor
cable
R, G/MONO, and B
connectors
Monitor power switch
Power off ( O )
Power on ( l )
014–002091
