To prevent damage to the
packing tray (you may need
to use it again), fold down the
narrow ends of the tray.
Place one foot on the tray,
and pull one end of the
computer unit out of the foam
cut–outs as shown.
Repeat the process
illustrated in (A) on the
opposite side to release the
entire computer unit from the
packing tray. Lift the unit
from the tray and place it in
your final installation site.
Save the entire shipping carton for possible future use.
Figure 1–7 Removing the Computer from the Packing Tray
014–002091
Push down
Pull up
Pull out
(A)
Released ends
(B)
Getting Started
Swing the unit to one side, and
balance the stand legs beside the
cut–outs on the packing tray foam.
Push down
Pull up
Pull out
