- Page 1 Prevista Dry Plus fixing rail for heavy loads Instructions for Use For hot water tank, pipes in self-supporting installation shafts Model Year built: 8570.35 from 11/2018 en_INT...
- Page 2 Prevista Dry Plus fixing rail for heavy loads 2 from 9...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview Handling Assembly information 3.1.1 Installation dimensions Assembly 3.2.1 Mounting in Prevista Dry Plus Disposal Prevista Dry Plus fixing rail for heavy loads... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g. -
Page 6: Product Information
Product information 2 Product information Intended use 2.1.1 Areas of use The Prevista Dry Plus fixing rail is used to fasten hot water tanks and pipelines in free-standing installation shafts in a Prevista Dry Plus pre- wall construction. Product description 2.2.1 Overview Fig. -
Page 7: Handling
Handling 3 Handling Assembly information 3.1.1 Installation dimensions Fig. 2: Dimensions Assembly 3.2.1 Mounting in Prevista Dry Plus Attach the fixing rail onto the open mounting rail using the slot nuts supplied. Insert the slot nut into the opening of the fixing rail. Prevista Dry Plus fixing rail for heavy loads 7 from 9... - Page 8 Handling Push the slot nut in until it engages. Set the height of the fixing rail. Fasten the slot nut. 25 Nm Bend the sides of the metal bars of the fixing element. Prevista Dry Plus fixing rail for heavy loads 8 from 9...
-
Page 9: Disposal
Handling Set the height of the fixing rail. Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Prevista Dry Plus fixing rail for heavy loads 9 from 9...
