- Page 1 Prevista Dry Plus washbasin module with concealed connection box Instructions for Use for WB with single-hole fitting Model Year built: 8545.32 from 03/2019 en_INT...
- Page 2 Prevista Dry Plus washbasin module with concealed connection box 2 from 19...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview 2.2.2 Compatible components 2.2.3 Technical data Accessories and spare parts Handling Assembly information 3.1.1... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g. -
Page 6: Product Information
Product information 2 Product information Intended use 2.1.1 Areas of use The Prevista Dry Plus washbasin module is designed for mounting in a Prevista Dry Plus pre-wall construction. Product description 2.2.1 Overview Fig. 1: Components and scope of delivery Washbasin module mounting bracket for concealed connection box Screws for fixing in support profile slot nuts... -
Page 7: Compatible Components
Product information 2.2.2 Compatible components The washbasin module is compatible with all common washbasin ceramics, even with larger projection (barrier-free). 2.2.3 Technical data Drain elbow (outlet side) DN 40 / 50 Rubber nipple DN 50 / 30 Fig. 2: Installation height A - 850 mm above UEFFL B - Observe the ceramic manufacturer's instructions C - Observe the ceramic manufacturer's instructions... -
Page 8: Accessories And Spare Parts
Product information Accessories and spare parts Spare parts Drain elbow, model 8064.90, art. no. 743208 chrome-plated with flanged rim Fig. 3: drain elbow Ready-to-install set, model 8314.5, art. no. 734848, consisting of Cover plate drain elbow drainpipe with flanged rim, 75 mm Fig. -
Page 9: Handling
Handling 3 Handling Assembly information 3.1.1 Mounting conditions Suitable walls Prevista Dry Plus pre-wall constructions The washbasin module may only be mounted on even wall surfaces. Construction height With the construction height, the marked height of the upper edge of the finished floor must be observed. - Page 10 Handling Seal the corner valve (e.g. using hemp). Screw the corner valve into the screw fitting. Seal and screw in a suitable pipeline adapter. INFO! Observe the additional markings when aligning the corner valves. Screw in until the connection to the washbasin fitting is between the markings.
- Page 11 Handling Mount the entire seats in the concealed connection box. ð The object can be heard locking into place. Mounting in Prevista Dry Plus The two vertical rails, which surround the module, must be open towards the module and have an inner distance of 420 mm.
- Page 12 Handling Set the height of the rail. Fasten the slot nut. 25 Nm Bend the sides of the metal bars of the rails. Bend the sides of the metal bars of the fitting holder. Prevista Dry Plus washbasin module with concealed connection box 12 from 19...
-
Page 13: Set And Clad The Module
Handling Set the height of the module according to the ceramic manufactur‐ er's instructions. 3.2.2 Set and clad the module Turn in the threaded rods by hand. Tighten the nuts of the threaded rods with a fork spanner (size 17). Place the protective caps on the threaded rods. - Page 14 Handling Cut the gypsum cardboard cladding panel to size. Clad the module with suitable gypsum cardboard cladding panels. Final assembly of the con‐ cealed connection box Remove the site protection. Cut the shaft of the concealed connection box flush with tiles. Prevista Dry Plus washbasin module with concealed connection box 14 from 19...
- Page 15 Handling Manufacture the connection for the washbasin fitting on one side using the copper pipe supplied. If necessary, cut the chrome-plated pipe elbow supplied to the cor‐ responding length. Manufacture the second connection on the other side in the same way.
- Page 16 Handling Align the corner valves. When doing so, align the pipe elbow to the marking aid (line on the concealed connection box). Remove the plug. Insert the drain elbow into the lip seal of the odour trap. If applicable, identify sizes on the drain elbow and adjusting pipe that may have to be shortened.
-
Page 17: Cleaning And Maintenance
Handling Set the odour trap to the right size at the height. The vertical setting range is 20 mm. Attach the cover plate to the concealed connection box. The lateral supports serve as a safeguard against distortion. Turn the drain elbow to the right and in doing so secure it to the washbasin. - Page 18 Handling Cut the water supply. Disconnect the water line from the corner valve. Turn the odour trap anti-clockwise. When doing so, unlatch the clip to the right. Lift up the odour trap. Remove the odour trap for cleaning. Pull out the adjusting pipe upwards to clean. Clean the odour trap.
-
Page 19: Disposal
Handling Replacing corner valves Cut the water supply. When replacing the corner valve, counter the screw fitting with a spanner (size 27). Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements.
