Invicta AKIMIX Reference page 27

Name:
Guide No.
1 1 Base
2 1 Regulator plate
3 1 Heavy duty locking screw
4 10 Washer L D8
5 1 Spring
6 31 Nut M6
7 4 Foot
8 4 M8 locking washer
9 4 TH M08x20 screw
10 1 Front plate
11 1 Window regulator
12 1 Air guide
13 3 FHC M6x35 screw
14 2 Locking wedge
15 1 Locking bracket
16 1 Locking connector
17 2 FHC M6x16 steel screw
18 1 Hearth door
19 1 Control rods
20 6 BHC M5x8 screw
21 1 Left-hand side
22 1 Internal surface
23 4 TH M8x60 screw
24 8 Nut M8
25 4 Washer L D6
26 6 TH M6x20 screw
27 1 Rear
28 1 Post-combustion regulator
29 2 Limiter
30 4 TBEHC M6x20 screw
31 4 ThM5x25 screw
32 8 M D5 washer
33 4 M5 nut
34 1 Floor plate
35 1 Upper insert
36 8 TBEHC M6x30 stainless steel screw
37 1 Hearth grill
38 1 Feed channel
39 1 Nozzle
40 6 M6x30 stud
41 4 M8x40 stud
42 1 Hopper
43 1 Front right-hand side
44 2 TH M6x10 screw
45 1 Top
46 2 Hinges
47 8 FHC M5x10 screw
48 1 Granule cover
49 10 FHC M6x20 screw
Français – English - Deutsch
DT, le 18/06/2019
AKIMIX Wood Stove
Item name
Reference 6190 34
Reference
F612200U
AT610443A
AS618100
AV4110080
AS750125
AV7220060
F612174U
AV4150080
AV8408200
F612201B
AT610442A
F612213B
AV8636350
AT610444
AT610441B
AS610235A
AV8636166
F612202U
AS610234D
AV8685080
F612204B
F612205B
AV8408600
AV7220080
AV4110060
AV8406200
F612206B
AT610451A
AT610112A
AV8696200
AV8405250
AV40900050
AV7100050
F612209B
F612177B
AV8696306
F612207B
F612216U
F610271B
AV8706300
AV8708400
AT610454D
F612211B
AV8406100
F612214U
AS610120B
AV8635100
F612215U
AV8636200
Page 27 sur 60
