Mahindra Genio DC BS-III Diagnostic Manual page 154

Diagnostic Manual (EMS)
Genio DC BS-III & BS-IV
Complete list of probable DTCs
DTC
P0100 Battery voltage error of HFM sensor
P1109 Correction factor 0 monitoring of the drift compensation function of AFS
P110A Correction factor 1 monitoring of the drift compensation function of AFS
P1104 Plausibility check of offset drift of airmass,ratio is higher than threshold high
P1103 Plausibility check of offset drift of airmass,ratio is lower than threshold low
P110B Signal error of AFS
P0103 Signal range check of airmass, voltage above upper limit
P0102 Signal range check of airmass, voltage below lower limit
P1400 AirControl permanent governor deviation positive governer deviation above limit
P1401 AirControl permanent governor deviation negative governer deviation below limit
P0563 Battery voltage above upper limit
P0562 Battery voltage below lower limit
P1792 Brake signal not plausible
CAN Bus off error
U0073
P2558 coolant temperature sensor minimum temperature not reached within timelimit
P1126 Temperature raised has not reached the minimum threshold within time limit
P0118 coolnat temperature sensor voltage above upper limit
P0117 coolnat temperature sensor voltage below upper limit
P0704 Main Clutch signal closed not plausible
P162D EEPROM error in erase opertion
P162B EEPROM error in last read operation
P162C EEPROM error in last write operation
P0403 Exhaust Gas Recirculation Actuator Power stage no load
P0404 Exhaust Gas Recirculation Actuator Power stage excess temperature
P0406 Exhaust Gas Recirculation Actuator Power stage short circuit to battery
P0405 Exhaust Gas Recirculation Actuator Power stage short circuit to ground
P1670 Shutoff request of the injection cutoff
P0108 Environment Pressure Sensor voltage above upper limit
P0107 Environment Pressure Sensor voltage below lower limit
P0341 Camshaft failure due to wrong camshaft signal
P0340 Camshaft failure due to no camshaft signal
P1340 Camshaft failure offset between crankshaft and camshaft
P0336 Crankshaft failure due to wrong crankshaft signal
P0335 Crankshaft failure due to no crankshaft signal
P0480 Fan control open load error
P0607 Fan control over temperature error
P0692 Fan control short circuit to battery
P0691 Fan control short circuit to ground
P2265 Water in fuel sensor faulty
Water presence in fuel error
P2269
P0183 Fuel Temperature sensor voltage above upper limit
P0182 Fuel Temperature sensor failure voltage below lower limit
P1737 IMA not flashed for cylinder 1
P1739 IMA not flashed for cylinder 3
P1740 IMA not flashed for cylinder 4
P1738 IMA not flashed for cylinder 2
P0202 Short circuit of injectors in bank
