Owner's Manual
__________________________________________________________________________________
Issue Date: September 2018
: Carefully read, understand and follow the instructions provided in this manual, and keep it in a safe place for future reference. If you have any
NOTE
doubt whatsoever regarding the use or care of your vehicle, please visit your Authorised Mahindra Dealer for assistance or advice.
This Owner's Manual should be considered as an integral part of the vehicle and should remain with the vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALTURAS G4 2019 and is the answer not in the manual?

Questions and answers

Gopal kirshan
April 25, 2025

Gadi mea chak engen light aa rahi hea jese start karte hea chak engin light cali jati he par gadi me gear nahi lagte or smoke deti hea gadi gear dalte hi chak ingen light aahat hea or gadi sahi chalne lagti he

User image 680b8ca913a8f
0
1 comments:
Mr. Anderson
May 12, 2025

The engine light in a 2019 Mahindra Alturas G4 may come on at startup due to issues in the fuel system, such as using low-quality fuel or fuel with high water content. This can trigger the water separator warning and cause serious engine damage. While the engine light is on, the vehicle may not shift gears or may produce smoke due to reduced engine performance or protective system limitations to prevent further damage. Once the issue clears or the system resets, normal operation may resume.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Mahindra ALTURAS G4 2019

Summary of Contents for Mahindra ALTURAS G4 2019

  • Page 1 NOTE doubt whatsoever regarding the use or care of your vehicle, please visit your Authorised Mahindra Dealer for assistance or advice. This Owner's Manual should be considered as an integral part of the vehicle and should remain with the vehicle.
  • Page 2 __________________________________________________________________________________ MAHINDRA & MAHINDRA LTD., GATEWAY BUILDING, APOLLO BUNDER, MUMBAI - 400 039 www.mahindra.com...

  • Page 3: Table Of Contents

    Safety Symbols ............... 1-2 Vehicle Care................. 2-13 General Safety Information and Instructions ....1-2 Precautions Regarding UnAuthorised Modification & To Owners of a Mahindra Vehicle........1-4 Alteration ................2-21 Lubricants and Capacities ........... 1-7 SAFETY UNIT ................... 3-1 Dimensions................1-8 Seat...................
  • Page 4 Table of Contents Airbag Non-inflation Conditions ........3-35 EPB (Electric Parking Brake)..........4-43 Warning and Caution............3-39 Double Parking ..............4-46 STARTING THE ENGINE AND DRIVING THE VEHICLE.... 4-1 AUTO Hold (if equipped) ............ 4-48 Engine Starting (Smart Key)..........4-1 Cruise Control Switch ............
  • Page 5 Table of Contents How To Set Power Tailgate (if equipped) ...... 5-22 Rear Air Conditioner (Dual A/C)........5-73 Smart Tailgate Operation (if equipped)......5-23 Defogging and Defrosting ..........5-74 Door Open Lever, Lock/Unlock Knob And Switch ..5-26 Multimedia................5-75 Opening And Closing Windows........
  • Page 6 Table of Contents LCD Display Pop-Up Message ......... 6-40 Bulb Specifications and Functional Check..... 8-17 IN CASE OF EMERGENCY ............. 7-1 Location of Exterior Lamps..........8-19 Tools Kit and Warning Triangle.......... 7-1 Replacing Air Conditioner Filter........8-21 Starting the Engine with Jumper Cable......7-2 Tyre ..................

  • Page 7: General Information

    Always make sure that your vehicle is in optimum working order, and take note of the road and weather conditions under which you • We recommend you always use genuine Mahindra spare parts are using your vehicle. when performing repairs on the vehicle •...

  • Page 8: Safety Symbols

    Never use a mobile phone or any device with headphone while NOTICE indicates important information relevant to the vehicle, driving. This may take your focus off the road and lead to the vehicle's use or to sections of this manual to which accidents. © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 9 We recommend that you use only genuine parts supplied by please contact your Authorised Mahindra Dealer or a qualified Mahindra. The use of non-Mahindra parts will not be covered technician. by warranty.

  • Page 10: To Owners Of A Mahindra Vehicle

    The condition communication equipment in vehicles in your country. should correct itself within 5-15 kms. of driving. If the disturbance persists, have the tyres checked by an Authorised Mahindra Dealer. Driving Long Distances Driving and Alcohol...
  • Page 11 Mahindra genuine parts will help retain emission performance of To avoid counterfeit parts and to protect our brand image, the vehicle and is a pre-requisite for emissions warranty coverage. Mahindra genuine parts are packed in a branded carton. Look for the “Mahindra Genuine Parts” logo. Servicing...
  • Page 12 Consult Authorised Mahindra Dealer for specific weight information • Bull bars and nudge guards are not recommended • Accessories causing any change in vehicle specifications like wheel rims, bull bars, etc., may affect the performance of...

  • Page 13: Lubricants And Capacities

    System Capacity Specification Lubricant Remarks Always use "MAXIMILE FEO" new generation Mahindra genuine engine oil. This is specially developed for your engine’s optimum performance and fuel efficiency. In extreme cases of emergency and non-availability of Special Engine MAHINDRA "MAXIMILE FEO"...

  • Page 14: Dimensions

    GENERAL INFORMATION 1.6 Dimensions Top View Front View 1960 Y4A003 1620 Y4A001 Rear View Side View 1845 2865 1090 4850 1620 Y4A002 Y4A004 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 15: Technical Specifications

    Idle speed 720 ± 50 rpm e-XDi220 Cooling system Water-cooled / forced circulation Coolant capacity (ℓ) 10.2 Lubrication type Gear pump, forced circulation Max. oil capacity (ℓ) Turbocharger, air-cooled Turbocharger and cooling type © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 16 Inner / Outer 39.6° / 33.6° — Drive shaft type Ball joint type Front Axle — Axle housing type Build-up type Drive shaft type Semi-floating type Rear Axle Axle housing type Build-up type © Copyright Mahindra and Mahindra Ltd. 092018 1-10...
  • Page 17 5-link + coil spring Air Conditioner R-134a / 850 ± 30g Refrigerant (capacity) Battery type / Capacity (V-AH) 12 - 90 Starter capacity (V-kW) 12 - 2.2 Electrical Alternator capacity (V-A) 14 - 140 1-11 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 18: Vehicle Identification

    3. Engine Number The chassis number is stamped on the frame centre of the long member. The engine number is stamped on the lower area of cylinder block behind the Intake manifold. © Copyright Mahindra and Mahindra Ltd. 092018 1-12...

  • Page 19: Quick Guide Front Overview

    Front Fog Lamp 8-19 Sunroof 5-34 Front Towing Hook 7-20 Outside Door Handle and Switch Parking Assist System (Front PAS) 4-56 Approach (Welcome) Lamp 5-7, 5-43 Around View Monitoring System 4-58 Engine Hood 5-31 1-13 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 20: Quick Guide Rear Overview

    Rear Glass Heater 5-70 Fuel Filler 5-32 Rear Wiper 8-14 Wheel And Tyre (TPMS) 7-5, 8-23 Licence Plate Lamp 8-19 Rear Parking Assist System 4-56 Rear View Camera 4-57 Rear Towing Hook 7-20 © Copyright Mahindra and Mahindra Ltd. 092018 1-14...

  • Page 21: Quick Guide Ip Overview - I

    Door Lever 5-27 HDC Switch 4-41 Driver Seat Easy Access 5-37 Tailgate Interior Switch 5-16 Opening/closing Windows 5-28 Front Obstacle Detection Warning OFF Switch 4-56 Outside Rearview Mirror Control Switch 5-58 Front Seats 1-15 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 22: Quick Guide Ip Overview - Ii

    4-36, 4-38 Wash Wiper Stalk 5-41 Cruise Control Switch 4-50 Driver Airbag 3-29 Instrument Cluster User Settings Switch 6-16 Interior Fuse Box 8-15 Steering Wheel Multimedia Switch 5-76 Opening/closing Engine Hood 5-31 © Copyright Mahindra and Mahindra Ltd. 092018 1-16...

  • Page 23: Quick Guide Ip Overview - Iii

    AVN, Smart Audio 5-76 Heater And A/C Controller 5-66 Front Seat Ventilation Switch EPB Switch 4-43 Slots For Multimedia 5-78 4WDSelection Switch 4-31 Front Power Socket 5-86 AUTO Hold Switch 4-48 TGS Lever 4-14 1-17 © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 24 Jack 7-1,7-12 Second Row Seat Window Switch 5-29 Rear Power Socket 5-86 Rear Cup Holder And Armrest 5-85 Luggage Board Second Row Seat Belt 3-16 Rear USB Charger 5-87 Second Row Seats © Copyright Mahindra and Mahindra Ltd. 092018 1-18...

  • Page 25: Engine Compartment

    1 Degassing Tank .........8-7 Dipstick ..........8-5 7 Battery ..........8-12 2 Brake Fluid Reservoir......8-9 Engine Oil Cap........8-5 8 Fuse and Relay Box ......8-15 3 Windshield Washer Fluid Reservoir ...8-10 Power Steering Reservoir ....8-11 1-19 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 26: Quick Guide (Warning And Indicator Lights)

    Lock) warning light warning lamp warning lamp Auto cruise HDC ON Turn signal/hazard warning Front fog lamp Cruise control Winter mode Ready indicator/ lamp indicator indicator indicator indicator indicator warning light Y4A015 © Copyright Mahindra and Mahindra Ltd. 092018 1-20...

  • Page 27: Safety Precautions

    • Make sure that there is not any trace of leak around the vehicle If the level of various types of fluids goes down very fast, have the vehicle checked and serviced at a Mahindra Dealer or • Check the state of various lamps Mahindra Authorised Service Centre.
  • Page 28 • Check and adjust the tyre inflation pressure, including the spare time. wheel, before any long journey. When driving the vehicle with insufficient tyre inflation pressure, the tyre could be blown out, because of standing wave symptom, resulting in severe injury and death © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 29 If it hinders the brake or accelerator pedal The travel range of the driver seat and steering wheel may vary operation, it may cause an unexpected accident depending on the vehicle model. © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 30 • Operate the EPB (Electric Parking Brake) switch and check if an operating sound is heard and the parking brake is applied. If the parking brake is not applied, have the vehicle checked and serviced at a Mahindra Dealer or Mahindra Authorised Service Y4F227 Y4F016 Centre •...
  • Page 31 • Keep the brake pedal depressed when releasing the parking Do not recline the seatback with the seat belt fastened. You brake could slide under the seat belt, which could result in serious injury or death. © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 32: Safety Instructions

    • A person who is smaller than 140 cm should sit in the rear seat • The air bags deploying in the front seat could harm your pet in an accident. Your pet should be restrained in the rear seat with pet harnesses or carriers © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 33 • Driving after taking medicine can be more dangerous than the restraint can cause severe injury or death to children. drunk driving depending on the medicine you took. Therefore, do not drive the car after taking medicine © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 34 • While sleeping in the car with the engine running, you may Opening a door during driving, especially by children, may cause accidentally step on the accelerator, thereby overheating the a serious accident engine and exhaust pipe and causing a fire © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 35 • Make sure that all passengers have their body parts such as hands inside the vehicle • When closing the windows, be aware of safety conditions before operation © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 36 And place the gear shift Do not accelerate the engine during the warming up period lever in “P” for vehicles • If possible, do not stop and park the vehicle on the steep road © Copyright Mahindra and Mahindra Ltd. 092018 2-10...
  • Page 37 For safety, we strongly recommend that you have an extinguisher in Abrupt operation of steering wheel makes the vehicle unstable and your vehicle. Keep it ready for use at any time. Be familiar with how may cause an accident. to use it. 2-11 © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 38 • Prolonged driving without proper ventilation can cause headache and dizziness. Set the air source selection switch to the fresh air © Copyright Mahindra and Mahindra Ltd. 092018 2-12...

  • Page 39: Vehicle Care

    • You can distinguish an authentic Mahindra genuine part by • Allow the engine to warm up after starting its hologram • Avoid harsh operations such as abrupt starts, sudden acceleration and prolonged high speed driving •...
  • Page 40 (calcium chloride etc.) has been spread, in the bumper area where the atmospheric fallout/industrial pollutants exists, or on a muddy or dusty road. Also, immediately wash your vehicle © Copyright Mahindra and Mahindra Ltd. 092018 2-14...
  • Page 41 Wipe vinyl or leather trim regularly with a clean damp cloth. Normal • If the bumper is contaminated by engine oil or any lubricants, trim soils, spots or stains can be cleaned with cleaners. wipe it off using mild soapy water 2-15 © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 42 Your windshield is clean if beads do not form when rinsing with water. © Copyright Mahindra and Mahindra Ltd. 092018 2-16...
  • Page 43 Mahindra vehicles are designed to operate under normal • Do not modify or apply additional sun films on the windshield environmental conditions and to withstand the natural elements.
  • Page 44 Never clean the alluminium wheel or alloy wheel with acidic or surfaces. alkalic detergents. Otherwise, wheel’s protective finish could be damaged. © Copyright Mahindra and Mahindra Ltd. 092018 2-18...
  • Page 45 Larger areas of finish damage • None of these items should be placed in the household can be corrected in your Mahindra Dealers body and paint shop. recycling bins or poured into the sewage system Underbody Maintenance •...
  • Page 46 • If the safety mode is activated, pull over and stop the vehicle to a safe location immediately and contact your Mahindra • When cleaning up interior parts, do not use chemical dealer. Then drive slowly or have the vehicle towed to a...

  • Page 47: Precautions Regarding Unauthorised Modification & Alteration

    If earthed during all noncommercial fueling operations. this happens, please visit the nearest Mahindra dealer or Mahindra Authorised Service Centre. 2.3.13 Water-in-Fuel Warning Lamp 2.4 Precautions Regarding UnAuthorised Modification &...
  • Page 48 In addition, other problems such as increase the vehicle, some drivers replace the flooring with laminated paper of fuel consumption and braking distance, vehicle’s shudder, and after removing the seats. However, this may cause damage to the © Copyright Mahindra and Mahindra Ltd. 092018 2-22...
  • Page 49 Do not instal products that may decrease the driving resistance such as sticker, moulding, air dam, or wind proofing products. 2-23 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 51: Safety Unit

    10. Second row seat 11. Head restraint 12. Armrest (cup holder) 11 11 14 13 13. Seat double folding lever (strap) 14. Seat back folding (reclining) lever (strap) 15. Third row seat * if equipped © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 52: Front Seat

    Adjust the head restraint so that it properly supports the head and neck. Do not apply excessive force to the head restraint during adjustment. It may get damaged. © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 53 The graphics on the switches guide you to the function it has been assigned. Do not adjust the driver’s seat when the vehicle is moving. Control of the vehicle can be lost. © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 54 • Do not adjust the driver’s seat when the vehicle is moving. Control of the vehicle could be lost Y4C009 • Pay attention to the passenger in rear seat when adjusting the seat © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 55: Second Row Seat

    ) or seat double strap ( ) releases the seatback lock. In this state, you can adjust folding strap ( ) to raise the folded seat. the seatback reclining or fold the seat. © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 56 The seat back can be folded down fully. Make sure that any the intervention area of the seat may be damaged. body part of the occupants is not caught by the folded seat back. © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 57 Unfold the seat in the reverse order of folding. Make sure that the seat is securely locked. If the seat is not locked, the seat may fold forward. © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 58: Third Row Seat

    To adjust the height of the folded seat and floor, lift of a collision. the luggage board up and insert it into the left and right grooves. © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 59: Front Seat Ventilation Switch (If Equipped)

    • Do not sit on the folded seat because the seat belt and other safety devices would not be able to protect you. It may cause serious injury in case of accident © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 60 • The battery can be discharged if the seat ventilation switch and current consumers are used with IGN ON (engine off) • Never try to adjust the seat while the vehicle is moving © Copyright Mahindra and Mahindra Ltd. 092018 3-10...
  • Page 61 • Do not insert your hands under the seat or in the path of the seat movement when adjusting the seat. Your hands or fingers could get trapped between the seat and the frame 3-11 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 62: Seat Belt

    (total 6 sec.) Buzzer will continue if seat belt are not fastened. Y4C028 © Copyright Mahindra and Mahindra Ltd. 092018 3-12...
  • Page 63 Operation of load limiter Mahindra Dealer or Mahindra Authorised Service centre After frontal collision, the load limiter releases the seat belt to • An infant or small child should always be restrained in an prevent the occupant from being injured due to belt force.

  • Page 64: How To Fasten The Three Point Seat Belt

    • Consult your doctor about seat belt position during pregnancy • The risk of injury in the event of an accident is increased for both the pregnant woman and unborn child if the seat belt is not worn © Copyright Mahindra and Mahindra Ltd. 092018 3-14...
  • Page 65 This may cause internal injuries • The shoulder belt should be positioned midway over the Make sure that the seat belt webbing is not twisted shoulder, never across the neck 3-15 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 66: Front Seat Belt

    • To unfasten the seat belt, press the button (B) on the buckle Y4C037 If you are not using the rear seat belt or trying to fold the rear seat, insert the seat belt webbing into the webbing guide on the side wall. © Copyright Mahindra and Mahindra Ltd. 092018 3-16...

  • Page 67: How To Fasten The Seat Belts (2-Point) In Second Row

    Put the lap belt as low as possible across the hips. Do not put it across waist. In an accident, the belt may apply pressure to your abdomen. This may cause serious internal injuries. 3-17 © Copyright Mahindra and Mahindra Ltd. 092018...

  • Page 68: Child Restraints And Pregnant Woman

    The force required to hold even an infant on your lap can become so great that you could not hold the child, no matter how strong you are © Copyright Mahindra and Mahindra Ltd. 092018 3-18...
  • Page 69 • Do not carry your child on your lap while driving. You cannot TYPE B resist against the impact pressure in an accident. The child TYPEA Y4C051 could be crushed between you and the parts of vehicle Y4C050 3-19 © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 70 UF: Suitable for forward-facing “universal” category restraints approved for use in the mass group. L: Suitable for particular child restraints given on attached list. These restraints may be of the “semi-universal” categories. X: Seat position not suitable for children in the mass group. © Copyright Mahindra and Mahindra Ltd. 092018 3-20...
  • Page 71 Always adjust the angle of the backrest before installing the child seat Do not use the car seat unless the following are met. The child seat may not perform as intended, which may result in a serious injury. 3-21 © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 72 Never instal a rear facing child restraint on the front seat play in all directions without ensuring that the front airbag is deactivated. Mahindra recommends that a child restraint to be installed on the rear • Make sure that the seat belt is routed through the rear- seat.
  • Page 73 • Child restraint anchorages are designed to withstand only positive location with the added benefit of easier and quicker those loads imposed by correctly-fitted child restraints. installation. Under no circumstances are they to be used for adult seat 3-23 © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 74 Use this as a child restraint system after engaging it by the lower latches. reference only. When you install a child restraint to your Therefore, do not secure the child restraint system only with © Copyright Mahindra and Mahindra Ltd. 092018 3-24...
  • Page 75 Römer KidFix XP Belted Forward facing Group I ISO/F2 22 to 36 kg Römer KidFix XP Belted Forward facing 9 to 18kg ISO/ ISO/F3 Key of letters be inserted in the above table 3-25 © Copyright Mahindra and Mahindra Ltd. 092018...
  • Page 76 3.11.8 Warnings for Seat Belt • Use only the officially approved child restraint Mahindra is not responsible for the personal injury and property • Always put on your shoulder belt over the shoulder and damage due to the defect of child restraint across the chest.
  • Page 77 Have the seat belt system checked by a Mahindra Dealer or Mahindra Authorised Service centre • Do not lock the seat belt with a clip or a clamp. If the seat belt is too loose, it may not protect your body from injury or •...
  • Page 78 © Copyright Mahindra and Mahindra Ltd. 092018 3-28...
