Diagnostic Manual (EMS)
Genio DC BS-III & BS-IV
Air Conditioning Power Stage
Description
Depending on the inputs received from the pressure switch and the Coolant temperature
sensor and the accelerator pedal demand, the EMS decides whether to turn on the AC,
switch off momentarily to meet the power demand calculated through accelerator pedal
input, or to switch it off permanently to reduce the load on the engine and thus avoid over
heating based on the input received from the coolant temperature.
DTC
P1531
DTC detection condition
Normal operation
• Depending on the above mentioned inputs and inbuilt
logics, the EMS gives or cut off ground to the
compressor clutch relay.
Malfunction
• The Compressor clutch relay driver detects open load.
Reaction
• BS III & BS IV – Sys Chk lamp on
• AC Compressor clutch will not get engaged.
All copyrights reserved by
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes
introduced by the manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or
whole of the present document, are prohibited without the prior written consent of Mahindra & Mahindra Ltd.
at the Authorized Service Centre of Mahindra & Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution© 2010 Mahindra &
Mahindra Ltd.
Diagnostic item
Short circuit to ground
• Shorted or wrong
The use of this document by any person other than the trained personnel,
MAN-00139-152
August 2011/Rev 1
P1531
Probable cause
connection of the AC
compressor clutch
relay.
