COMX-P2020 Module Installation and Use (6806800K97F)
Controls, LEDs, and Connectors
DMA2_DDONE0_B
DDR Debug
(cfg_ddr_debug)
PU / PD Resistors
1
Debug information is driven on the ECC pins
0
instead of normal ECC I/O. ECC signals from
memory devices must be disconnected.
Debug information is not driven on ECC pins. ECC
1
pins function in their normal mode.
LAD[0:15]
General Purpose POR
(cfg_gpinput[0:15])
PU / PD Resistors
No default
General-purpose POR configuration vector to be
-
places in GPPORCR.
LVDD_VSEL
eTSEC1,2,3; Ethernet Management; 1588 interfaces
PU / PD Resistors
No default
0
3.3V
1
2.5V
59
