Controls, LEDs, and Connectors
3.2.2.2

PHY Address Settings

Table 3-7
PHY
P2020 Internal TBI PHY
GEPHY #1 (U14)
GEPHY #2 (U15)
2
3.2.2.3 I C Bus #1 Address Setting
Table 3-8
IIC1
IIC EEPROM (U7)
IIC MUX (U45)
IIC EEPROM (U53)
USB HUB2 (U37)
2
3.2.2.4 I C Bus #2 Address Setting
Table 3-9
IIC2
LM75 (U17)
DDR3 (XJ1)
RTC (U30)
USB HUB1 (U12)
46
PHY Address Settings
2
I C Bus #1 Address setting
2
I C Bus #2 Address setting
COMX-P2020 Module Installation and Use (6806800K97F)
Controls, LEDs, and Connectors
Description
0X1F
0X00 0X01
0X02
Address
0XA0 (Strapping)
0XE0
0XA8 (Module type)
0X58 (NC)
Address
0X90
0XA6 0X66 0X36
0XD0
0X58 (NC)
