Signal name
Function
Select Option
Default value
Supported configuration
Signal name
Function
Select Option
Default value
Supported configuration
Signal name
Function
Select Option
Default value
Supported configuration
COMX-P2020 Module Installation and Use (6806800K97F)
Controls, LEDs, and Connectors
LGPL3/LFWP, LGPL5
Boot Sequencer
(cfg_boot_seq[0:1])
PU / PD Resistors
11
00 Reserved
Normal I2C addressing mode is used. Boot
sequencer is enabled and loads configuration
01
information from a ROM on the I2C 1 interface. A
valid ROM must be present.
Extended I2C addressing mode Is used. Boot
sequencer is enabled and loads configuration
10
information from a ROM on the I2C 1 interface. A
valid ROM must be present.
Boot sequencer is disabled. No I2C ROM is
11
accessed.
TSEC2_TXD1
DDR SDRAM Type
(cfg_dram_type)
PU / PD Resistors
1
0 DDR2; 1.8v
1 DDR3; 1.5v
LGPL1
eTSEC2 SGMII Mode
(cfg_sgmii2)
PU / PD Resistors
1
The eTSEC2 Ethernet interface operates in SGMII
0
mode and uses SGMII SerDes lane 2 pins.
The eTSEC2 Ethernet interface operates in parallel
1
mode and uses the eTSEC2_* pins.
