Controls, LEDs, and Connectors
Table 3-1
COM Express Connector (continued)
Pin
Signal
A65
Not Connected
A66
GND
A67
MUX_SHDC_D2
A68
Not Connected
A69
Not Connected
A70
GND
A71
LVDS_LDC0_P
A72
LVDS_LDC0_N
A73
LVDS_LDC1_P
A74
LVDS_LDC1_N
A75
LVDS_LDC2_P
A76
LVDS_LDC2_N
A77
G_LVDS_ENAVDD
A78
LVDS_LDC3_P
A79
LVDS_LDC3_N
A80
GND
A81
LVDS_LCC_P
A82
LVDS_LCC_N
A83
LVDS_IIC_SCL
A84
LVDS_IIC_SDA
A85
MUX_SHDC_D3
A86
Not Connected
A87
Not Connected
42
Pin
Signal
B65
Not Connected
B66
Not Connected
B67
Not Connected
B68
Not Connected
B69
Not Connected
B70
GND
B71
Not Connected
B72
Not Connected
B73
Not Connected
B74
Not Connected
B75
Not Connected
B76
Not Connected
B77
Not Connected
B78
Not Connected
B79
G_LVDS_ENABKL
B80
GND
B81
Not Connected
B82
Not Connected
B83
LVDS_PWM
B84
V5SB_COME
B85
V5SB_COME
B86
V5SB_COME
B87
V5SB_COME
Pin
Signal
C65
Not Connected
C66
Not Connected
C67
LDP1
C68
Not Connected
C69
Not Connected
C70
GND
C71
Not Connected
C72
Not Connected
C73
Not Connected
C74
Not Connected
C75
Not Connected
C76
GND
C77
LA<28>
C78
Not Connected
C79
Not Connected
C80
GND
C81
GPIO11
C82
LCLK1
C83
IRQ1
C84
GND
C85
IRQ2
C86
LA<23>
C87
GND
COMX-P2020 Module Installation and Use (6806800K97F)
Pin
Signal
D65
Not Connected
D66
Not Connected
D67
GND
D68
Not Connected
D69
Not Connected
D70
GND
D71
Not Connected
D72
Not Connected
D73
Not Connected
D74
Not Connected
D75
Not Connected
D76
GND
D77
LGPL5
D78
Not Connected
D79
Not Connected
D80
GND
D81
LA<26>
D82
LA<27>
D83
LA<24>
D84
GND
D85
LA<25>
D86
LCS6#
D87
GND
