X486
MODEL V9315H SERIES
ENVIRONMENTAL HOUSING
Copyright © 2004 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 516-952-CCTV (2288) FAX: 516-951-CCTV (2288) TOLL FREE: 800-645-9116
UK: 44/(0) 1489-566300
WEB: www.vicon-cctv.com
Vicon part number 8006-8486-03-01
Section 7 Rev 204
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vicon V9315H Series
Summary of Contents for Vicon V9315H Series
- Page 1 Copyright © 2004 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788 TEL: 516-952-CCTV (2288) FAX: 516-951-CCTV (2288) TOLL FREE: 800-645-9116 UK: 44/(0) 1489-566300 WEB: www.vicon-cctv.com...
-
Page 5: Table Of Contents
Contents Introduction .........................1 Installation ...........................3 Unpacking and Inspection..........................3 Inspection For Visible Damage........................3 Inspection For Concealed Damage ......................3 Mounting the Housing ...........................3 Camera Installation ............................4 Wiring the Unit ..............................5 Operation ..........................7 Maintenance ........................7 Shipping Instructions ......................8 Technical Information ......................9 Contents • i X486-03-01 Rev 204 V9315H... - Page 6 List of Figures Figure 1 Mounting Plate Dimensions ..........................4 Figure 2 Wiring Diagram ..............................6 ii • List of Figures X486-03-01 Rev 204 V9315H...
- Page 7 Use only with a mounting accessory recommended by Vicon, or sold with the video product. Any mounting of the video product should follow Vicon’s instructions, and a mounting accessory recommended by Vicon should be used.
- Page 8 When installing an replacement parts specified by Vicon or that have the outside cable system, extreme care should be taken to same characteristics as the original part. Unauthorized...
-
Page 9: Introduction
Introduction The information in this instruction manual covers the installation and maintenance of the V9315H Series of Environmental Housings. This unit should be installed by a qualified technician using approved materials in accordance with national, state and local codes. Read these instructions through completely before attempting installation. - Page 10 NOTES 2 • Introduction X486-03-01 Rev 204 V9315H...
-
Page 11: Installation
Installation Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver the equipment in the same condition as it left the factory. Inspection For Visible Damage Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s freight bill. -
Page 12: Camera Installation
Figure 1 Mounting Plate Dimensions Camera Installation 1. Disengage the two (2) side latches to open the cover. 2. Remove the camera mounting plate from the housing by loosening the four (4) Phillips head screws used to secure the plate. Slide the plate off the screws using the key slot holes. 3. -
Page 13: Wiring The Unit
Wiring the Unit The V9315H housing is provided with two liquid-tight compression fittings on the bottom (toward the back), which allow routing of the video, power and control cables to the inside of the housing. A wiring diagram is provided on the inside cover for reference. Note for 230 VAC installations only: A readily accessible disconnect device is required to be incorporated into the site wiring. - Page 14 Figure 2 Wiring Diagram 6 • Installation X486-03-01 Rev 204 V9315H...
-
Page 15: Operation
Operation Refer to the instruction manuals for the individual camera and lens for operation. Maintenance The housing needs no maintenance other than the occasional cleaning of the window, using plain soap and water. Do not use abrasive cleaners which scratch the window surface. Operation •... -
Page 16: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 17: Technical Information
Technical Information ELECTRICAL Input Voltage: V9315HC-HS: 120 VAC. V9315H-HS-24: 24 VAC. V9315HC-HS-230: 230 VAC. Power Consumption: Housings with heaters: 60 W. Heat Equivalent: Housings with heaters: 3.4 btu/min (0.85 kg-cal/min). Note: These figures represent the conversion of 100% of the electrical energy to heat. - Page 18 Maximum Camera/ Lens Dimensions: Fits camera/lens combinations of up to 13 in. (330 mm) long, 3.0 in. (76 mm) high, and 4.25 in. (108 mm) wide. Lens Mounting Plate Heater Clearance: 0.25 in. (6.4 mm). Weight: Approximately 6.5 lb (2.9 kg). Construction: End Caps: plastic, light gray.
