Disclaimer AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...
Safety Instructions When installing, operating, or performing maintenance on this equipment, the following safety precautions should always be taken into account in order to reduce the risk of fire, electric shock, and personal injury. Carefully read the safety instructions below before using this product. •...
This document pellucidly presents a brief overview of the product design, device installation, and firmware settings for the Pavo motherboard. For the latest version of this user's manual, please refer to the AIC website: https://www.aicipc.com/en/productdetail/20854.
1 x Mini-SAS HD OCP Mezzanine V2.0 Connector Supports 4 x SATA3 AIC MAX I/O™ 2.0 PCIe Gen3 x Total Supports 64 Lanes + 5 x SATA + 1 x USB 2.0 Product features and specifications are subject to change without notice.
Remote Management Processor (Apache Pass) support Graphics • PCIe VGA/2D Controller • 1920x1200@60Hz 32bpp • 1 x AIC Max I/O® supports: PCIe Gen3 total 64 lanes + 5 x SATA + 1 x USB2.0 Expansion 11 x SATA 6.0 Gb/s ports Slots •...
AIC Max I/O™ 2.0 to maximize system expansion and operating speed. In addition to integrating speed and system expansion to the server board, Pavo offers immediate and efficient management with Onboard Baseboard Management Controller and greater I/O extension.
Chapter 2� Hardware Setup Chapter 2. Hardware Setup Pavo User Manual This chapter provides the graphic detail and basic instruction for hardware installation. Turn off the system and unplug all peripheral devices before proceeding. 2�1 Central Processing Unit Setup The serverboard supports dual Xeon scalable processors and Socket P0 (LGA-3647).
Page 13
Pavo User Manual Chapter 2. Hardware Setup Processor Socket Assembly: The server board includes two processor sockets (LGA-3647), supports one or two of the Intel® Xeon® Processor Scalable Family and has a Thermal Design Power (TDP) of up to 165W on selected models.
Page 14
Chapter 2. Hardware Setup Pavo User Manual The PHM sits level with the processor socket assembly. The PHM is NOT installed properly if it does not sit level with the processor socket assembly. Once the PHM is seated over the processor socket assembly, the four heat sink torque screws must be tightened in order as shown below.
Pavo User Manual Chapter 2. Hardware Setup 2�2�4 Memory Installation Step 1 Unlock the dimm socket by pressing the retaining clips outward. Step 2 Insert the memory module into the slot. Make sure that the DIMM notch is accurately positioned.
Chapter 3� Motherboard Settings Pavo User Manual Chapter 3. Motherboard Settings This section describes the jumpers, internal connectors, and internal LED settings on the Pavo motherboard. The motherboard layout and jumper settings are listed below. 3�1 Block Diagram...
Connector and Header Location Connector and Header Location RJ45 Port for BMC management PMBUS Header (For Pavo systems only. Rack not included.) COM Port by 3.5mm Phone Jack PCIe Slot (x24) 2 x USB 3.0 Type A PCIe Slot (x16) Connector...
Page 25
Pavo User Manual Chapter 3. Motherboard Settings A Clear CMOS Jumper (J10) E ME Recovery Mode Jumper (J35) Setting Setting Pin 1-2 Normal Default Short ME Recovery Mode Pin 2-3 Clear CMOS Open Normal Default B BMC Reset Jumper (J23)
Page 26
Pavo User Manual Chapter 3. Motherboard Settings J XDP Port Setting CPU0 Bypass chain control (J83) Setting Force Bypass of Pin 1-2 CPU0 Pin 2-3 Normal Default K XDP Port Setting CPU1 Bypass chain control (J84) Setting Force Bypass of...
Pavo User Manual Chapter 3. Motherboard Settings 3�5 System LED Indicator 3�5�1 Front Panel Yellow System is On. System is in Standby; System is off, but has Power Blinking AC power. System has no AC power. Blue System ID activity is detected.
Pavo User Manual Chapter 3. Motherboard Settings 3�5�3 Rear PCH LAN Green LAN1 activity is detected. LED5 LAN1 is not active. Green LAN1 link is detected. LED7 LAN1 is not linked. Green LAN0 activity is detected. LED6 LAN0 is not linked.
Pavo User Manual Chapter 3. Motherboard Settings 3�5�4 Rear UID and Internal LED UID activity is detected. LED1 UID is not active. BMC Rack LAN activity is detected (Only for Rack). LED2 BMC Rack LAN is not active (Only for Rack).
Chapter 4. BIOS Configuration Settings Pavo User Manual Chapter 4. BIOS Configuration Settings This chapter demonstrates how to configure the UEFI BIOS settings in your system device. You can enter the BIOS screen during system startup. To enter BIOS configuration settings, •...
Pavo User Manual Chapter 4. BIOS Configuration Settings 4�2 BIOS Setup 4�2�1 Menu Press and to select the options of the menu bar. Press Enter to access the option screen. Menu Description Main Displays basic system information and date & time.
Page 32
Pavo User Manual Chapter 4. BIOS Configuration Settings There will be a message “Entering SETUP” displayed on the diagnostics screen. Identify the BIOS version. NOTE For the official released version, the last digit of the BIOS version must end in a “0.“...
Page 33
Pavo User Manual Chapter 4. BIOS Configuration Settings Load Optimal Default Setting. Save the setting and exit the BIOS setup utility.
Pavo User Manual Chapter 4. BIOS Configuration Settings 4�2�3 Update To identify the latest BIOS version, please check the BIOS setup.
Page 35
Pavo User Manual Chapter 4. BIOS Configuration Settings Update BIOS by INSYDE H2OFFT-D utility under DOS environment If you need to update Flash in the DOS environment, please use H2OFFT-D utility. To use this utility, you must include the flash.bat , H2OFFT-D.exe, and bin file in the same folder.
Pavo User Manual Chapter 4. BIOS Configuration Settings 4�2�4 DCPMM Setup Refer to section 4.2.2 step 1 and 2 to enter the Front Page menu. Enter the option "Device Management." In "Device Management" page, enter "Intel(R) Optane(TM) DC Persistent Memory...
Page 37
Pavo User Manual Chapter 4. BIOS Configuration Settings Intel(R) Optane(TM) DC Persistent Memory Configuration • DIMMs...
Page 38
Pavo User Manual Chapter 4. BIOS Configuration Settings • Regions • Namespaces...
Page 39
Pavo User Manual Chapter 4. BIOS Configuration Settings • Total Capacity • Diagnostics...
Pavo User Manual Chapter 4. BIOS Configuration Settings 4�3 Main Main Option Key: 4�3�1 Main Main System time Configures the current time. System date Configures the current date.
Pavo User Manual Chapter 4. BIOS Configuration Settings 4�4�4 SIO AST2500 SIO AST2500 Serial Port A Auto [Enable] Disable Base I/O Address [3F8] Interrupt IRQ3 [IRQ4] Serial Port B Auto [Enable] Disable Base I/O Address [2F8] Interrupt [IRQ3] IRQ4 Serial Port D...
Pavo User Manual Chapter 4. BIOS Configuration Settings 4.4.6 ME Configuration ME Configuration Altitude Min=0x0, Max=0xffff, [0x8000] Server ME General ME Configuration Configuration MCTP Bus Owner Min=0x0, Max=0xffff, [0x0] ME Initialization Min=0, Max=12, [2] Complete Timeout Enable HSIO [Enable] Disable...
Pavo User Manual Chapter 4. BIOS Configuration Settings 4.4.7 PCH Configuration PCH Configuration PCH Devices PCH state after G3 [S5] Last State SATA Controller [Enable] Disable Configure SATA as [AHCI] RAID Support Aggressive Link Power [Enable] Disable Management Port 0~7...
Pavo User Manual Chapter 4. BIOS Configuration Settings 4�8 Exit Exit Option Key: 4�8�1 Exit Save and Exit Exit Saving Changes Exit system setup and save your changes. Save Change Without Exit Save your changes without exiting the system. Exit Discarding Changes Discard your changes when existing the system.
Chapter 5. BMC Configuration Settings Pavo User Manual Chapter 5. BMC Configuration Settings Chapter 5. BMC Configuration Settings Insert Ethernet LAN cable into the BMC LAN port. There are two methods to setup BMC IP: BMC management port 5�1 Method 1 (Use the BIOS Setup) Step 1 BIOS SETUP ...
Page 58
Pavo User Manual Chapter 5. BMC Configuration Settings...
Page 59
Pavo User Manual Chapter 5. BMC Configuration Settings Step 3 Type in the subnet mask address. Step 4 Type in the gateway address.
Pavo User Manual Chapter 5. BMC Configuration Settings 5�2 Method 2 (Use a Dos Tool - Syscheck) Step 1 Type in "sc –lanset" Step 2 Modify the IP setting. NOTE Type 1 for selecting Static IP Mode or type 2 for selecting DHCP Mode.
Page 61
Pavo User Manual Chapter 5. BMC Configuration Settings Step 4 Type in the submask address. The IP address below is an example using a default IP setting. The IP address is configurable. Step 5 Configure the gateway address to complete the BMC IP setting.
Pavo User Manual Chapter 5. BMC Configuration Settings 5�3 Login NOTE This feature works with JAVA 6 Runtime installed Console Environment The IP source default is DHCP. You can change the IP source to DHCP or Static by the BIOS utility or the system check.
Pavo User Manual Chapter 5. BMC Configuration Settings 5�4 Web GUI 5�4�1 Menu Bar Click to select the options of the menu bar. Menu Description The Dashboard page gives the overall information about the status of a Dashboard device. Sensor The Sensor Readings page displays all the sensor related information.
Pavo User Manual Chapter 5. BMC Configuration Settings 5�4�2 User Information and Quick Button The user information and quick access buttons are located at the top right corner. It displays the logged-in user, his/her privilege and the four quick buttons allowing you to perform different functions.
Pavo User Manual Chapter 5. BMC Configuration Settings 5�4�3 Dashboard The Dashboard page gives the overall information about the status of adevice. 5�4�4 Sensor The Sensor Readings page displays all the sensor related information. 5�4�5 FRU Information The FRU Information page displays Basic Information, Chassis Information, Board Information and Product Information of the FRU device.
Pavo User Manual Chapter 5. BMC Configuration Settings 5�4�6 Logs and Report The System Inventory page displays IPMI Event Log and Video Log. Click Logs and Reports from the menu bar. 5�4�7 Settings The Settings page allows you to access various configuration settings.
Pavo User Manual Chapter 5. BMC Configuration Settings KVM Mouse Setting The KVM Mouse Setting page allows you to configure the mouse mode to relative, absolute, and other. • For Windows OS environment, set mode to absolute. • For Linux OS environment, set mode to relative.
