SETUP – SD-R2002
Toshiba recommends that only trained professionals install this CD-RW/DVD-ROM Combo drive into
The SD-R2002 CD-RW/DVD-ROM Combo drive has no jumpers that need to be set
Mounting orientation: 15° (horizontally), 15° vertically (volume control in down position), 30°
(drive with volume control in up position).
When mounting drive use 4 M2-PO.4 tapping holes located on the left and right sides of drive.
When mounting drive, the tightening torque of the four screws must be even. Recommended
screw tightening torque is 2N
For clearance around the front bezel, it is recommended that a clearance of more than 0.8mm
should be left in all directions.
Toshiba's SD-R2002 drive does not require any unique device drivers for Windows '98/2000/XP/NT.
After installing your drive and re-booting, your system should recognize your drive. Win '98/2000/XP/NT
Operating Systems support all Toshiba's ATAPI drives natively. If you prefer using DOS, download the
ATAPI driver from our web site.
