SD-R1002
CD-RW/DVD-ROM COMBO DRIVE
USER MANUAL

Advertisement

   Also See for Toshiba SD-R1002

   Related Manuals for Toshiba SD-R1002

   Summary of Contents for Toshiba SD-R1002

  • Page 1

    TOSHIBA AMERICA INFORMATION SYSTEMS STORAGE DEVICE DIVISION IRVINE, CALIFORNIA SD-R1002 CD-RW/DVD-ROM COMBO DRIVE USER MANUAL...

  • Page 2: Table Of Contents

    CONTENTS Introduction...1 Setup ...3 Using the Combo Drive ...6 Troubleshooting...9 Specifications ...10 Drive Connectors...13...

  • Page 3: Introduction

    INTRODUCTION – SD-R1002 General Features CD-RW disc write/rewrite at 1X, 2X and 4X 3-way Disc Eject (eject button, software, emergency eject hole) Average Random Access Time 110ms DVD-ROM 160ms Horizontal or Vertical Mount 2MB Buffer Playback interchangeability for CD-ROM and DVD-ROM discs...

  • Page 4

    Front Panel Figure 1.SD-R1002 DVD Writeable Drive Front Panel Loading Tray Load disc using tray. LEDs The LED lights green or amber when the drive is operating (LED is amber when drive is writing.) Load/Unload Button The Load/Unload button is used to open the disc tray so you can install or remove a disc.

  • Page 5: Setup

    SETUP – SD-R1002 The following steps must be performed to properly install your drive: • Set Drive Jumper Settings • Connect Audio Cable • Attach IDE BUS Cable • Attach Power Cable • Mount Drive Jumper Settings The mode select jumpers are 6 straight angle pins located on the rear of the Combo drive.

  • Page 6

    If the Combo drive is replacing a CD-ROM or DVD-ROM, remove drive presently installed in your system. Your Toshiba Combo drive can be placed in any free half-height drive slot at the front of your computer. (It can be mounted horizontally or vertically.) Carefully start sliding the Combo drive into the opening with the disc tray facing the front of the computer.

  • Page 7

    DOS, download the DOS ATAPI driver from our web site. Other Software - Additional software is required to use the SD-R1002 CD-R/-RW and DVD functions. When you purchase the SD-R1002 as a kit, it will include the following software (Nero6): •...

  • Page 8: Using The Combo Drive

    USING THE DVD Combo Drive – SD-R1002 Drive Operation Inserting a Disc - Horizontally To insert a disc into a drive that is mounted horizontally, perform the following steps: Figure 1.Inserting Disc 1. Open the drive's Loading tray by pressing the Eject Button.

  • Page 9

    3. Grasp disc by edges, and lift out of loading tray. 4. Press Eject Button again to close Loading Tray. Software When you purchase the SD-R1002 as a Kit, it will include Nero6 OEM Suite Software, which is used to create CDs and view DVDs. Usage Guidelines •...

  • Page 10

    Emergency Ejection CAUTION: The following procedure is intended only as a last resort when pressing the eject button fails to open the Loading Tray 1. Turn computer power OFF by properly shutting down system. 2. Insert a solid bar (i.e. large paper clip) into Emergency Eject hole and push in until loading tray opens.

  • Page 11: Troubleshooting

    TROUBLESHOOTING – SD-R1002 Problem Disc tray cannot be opened Drive is not recognized by system Drive is not recognized by system during Boot process, recognized Operating System (i.e. XP, Win2000, Win98, Win NT, etc.) BUSY Indicator LED flashes slowly BUSY Indicator LED is constantly...

  • Page 12: Specifications

    SPECIFICATIONS – SD-R1002 General Interface: ATAPI Applicable Formats - Write: Formats for Writing Disc at once, Track at once, session at once, Packet Write, incremental write, restricted overwrite Applicable Write Disc – CD-DA, CD+(E)G, CD-MIDI, CD-ROM, CD-ROM XA, CD-I, MIXED MODE...

  • Page 13

    Transfer Rate DVD-ROM CD-ROM Random Access Time Data Error Rate DVD-ROM CD-ROM Data Buffer Reliability MTBF Power ON Hours ON/OFF Cycles Number of Access Operating Duty Cycle MTTR Environmental Ambient Temperature Operating Storage Shipping Temperature Gradient Operating Storage/Shipping Relative Humidity Operating Storage/Shipping Vibration...

  • Page 14

    Height Width Depth Weight Connectors DC input ATAPI Interface Connector Audio Connectors Regulatory The SD-R1002 Combo drive has been certified by the following regulatory agencies: • UL 1950 • CSA C22.2 No. 950 • TUV (EN60950I) • CE standard •...

  • Page 15: Drive Connectors

    ON Audio Supplies Analog and Digital sound to your system. Connectors The SD-R1002 DVD drive is connected to your computer system through the ATAPI ATAPI connector Connector The mode select jumpers are 6 straight angle pins located on the rear of the DVD drive.

  • Page 16

    Table 1.Interface Pin Assignments SIGNAL HOST SIGNAL NAME NAME Reset Host Reset Host Data Bus BIT 7 Host Data Bus BIT 8 Host Data Bus BIT 6 Host Data Bus BIT 9 Host Data Bus BIT 5 HD10 Host Data Bus Bit 10 Host Data Bus BIT 4 HD11 Host Data Bus BIT 11...
