INTRODUCTION – SD-R1612 General Features CD-R/CD-RW disc write/rewrite at 52X/32X 3-way Disc Eject (eject button, software, emergency eject hole) Average Random Access Time CD-ROM/CD-R 95ms CD-RW 110ms DVD-ROM - Single 110ms DVD-ROM - Dual 130ms DVD-RAM 200ms Horizontal or Vertical Mount 2MByte Buffer Playback interchangeability for CD-ROM and DVD-ROM discs Regionalization (RPC2 compliance) (DVD)
SETUP – SD-R1612 The following steps must be performed to properly install your drive: • Set Drive Jumper Settings • Connect Audio Cable • Attach IDE BUS Cable • Attach Power Cable • Mount Drive Jumper Settings The mode select jumpers are 6 straight angle pins located on the rear of the Combo drive. By placing a jumper on the pins, you can select the following functions: Drive is configured using host interface signal CSEL Configures drive as Slave...
If the Combo drive is replacing a CD-ROM or DVD-ROM, remove drive presently installed in your system. Your Toshiba Combo drive can be placed in any free half-height drive slot at the front of your computer. (It can be mounted horizontally or vertically.) Carefully start sliding the Combo drive into the opening with the disc tray facing the front of the computer.
Figure 6.Mounting Illustration Software Driver - Toshiba's optical drives do not require any unique device drivers for Windows '95/'98/2000/Me/XP/NT. After installing your drive and re-booting, your system should recognize your drive. Windows '95/'98/2000/Me/XP/NT Operating Systems support all Toshiba optical drives natively If you prefer using DOS, download the DOS ATAPI driver from our web site.
USING THE DVD Combo Drive – SD-R1612 Drive Operation Inserting a Disc - Horizontally To insert a disc into a drive that is mounted horizontally, perform the following steps: Figure 1.Inserting Disc 1. Open the drive's Loading tray by pressing the Eject Button. 2.
Figure 2.Inserting Disc Vertically Removing a Disc To remove a disc from the Combo drive, perform the following steps: 1. Open the Loading Tray by pressing the Eject Button. 2. Slide disc holders away from disc. 3. Grasp disc by edges, and lift out of loading tray. 4.
Emergency Ejection CAUTION: The following procedure is intended only as a last resort when pressing the eject button fails to open the Loading Tray 1. Turn computer power OFF by properly shutting down system. 2. Insert a solid bar (i.e. large paper clip) into Emergency Eject hole and push in until loading tray opens.
TROUBLESHOOTING – SD-R1612 Solution Problem • Disc tray cannot be opened Check that there is power to drive. • Use Emergency Eject instructions to open tray. • Drive is not recognized by system Is the drive connected properly? Are all cables plugged in properly (e.g. Power Cable, Interface Cable and Audio Cables).
SPECIFICATIONS –SD-R1612 General Interface ATAPI Formats for Writing Disc at once, Track at once, session at once, Variable & Fixed Packet Write Format Compatibility: CD CD-DA (Red Book) CD-ROM (Yellow Book, Mode 1&2) CD-ROM XA (Mode 2, Form 1&2) CD-I (Green book, Mode 2, Form 1&2, Ready, Bridge) CD-Extra/CD-Plus (Blue Book) Video CD (White Book) CD-R (Orange Book Part II)
Performance Transfer Rate DVD (Single) 21,600KB/second DVD (Dual) 13,500KB/second 7,800KB/second (mode 1) CD-R/RW 6,000KB/second (mode 1) Random Access Time CD-ROM, CD-R 95ms CD-RW 110ms DVD Single 110ms DVD Dual 130ms DVDR/RW 130ms DVD-RAM 200ms Data Buffer Environmental Temperature Operating 0° to 50° C (32° to 122° F) Storage -40°...
Connectors DC input 4-pin Power Supply Connector ATAPI Interface Connector 40 Pin I/F ATAPI Standard Audio Connectors 4-pin and 2-pin connector (use matching housing, Part No. 70066, made by Molex Corp, or equivalent) Regulatory The SD-R1612 Combo drive has been certified by the following regulatory agencies: •...
DRIVE CONNECTORS –SD-R1612 Figure 1.SD-R1612 Combo Drive Rear Panel - Connectors Power Power is supplied to your Combo drive by the connection with your computer's +5V/+12V power cable to the power socket at the back of drive. One side of the plug has chamfered Connector edges, so the power connector fits only one way.
Table 1.Interface Pin Assignments INTERFACE PIN ASSIGNMENT SIGNAL HOST SIGNAL NAME SIGNAL HOST SIGNAL NAME NAME NAME Reset Host Reset HDRQ DMA Request Host Data Bus BIT 7 HWR-,STOP Host I/O Write Host Data Bus BIT 8 Host Data Bus BIT 6 HRD-, Host I/O Read HDMARDY, -...
