CCTR-831 OBD GPS Tracker Using Guide
-201811
Welcome to use this OBD GPS tracker CCTR-831, This product can upload current location to
website, display history tracking on website, it is very slim & anti-installation, connect the tracker to
the vehicle OBD socket is OK, also shock sensor is built in to control power saving, shock & move
alarm, built in rechargeable polymer battery 200mAH for power down alarm (tracker removed alarm),
shock alarm, move alarm, over speed alarm, etc.
Note: This tracker only get power supply from the OBD socket for easy installation, it have not CAN
BUS interface, and it can not get any vehicle status from OBD)
With GPS and GSM, the tracker sends the present location information through GPRS to internet
server, so that user visit the website
www.999gps.net
with the applied user's name and password
(the default user name is last 6 digits of the tracker ID, password is same with user name or 123456)
through any computer with available internet, and without downloaded any software. And it can help
to arrange the whole fleet or the vehicles of company or group or personal vehicles.
Also user can download Android or iOS app software to mobile phone, click the app, logon with user
name and password, you can locate current location & display history tracking, the user name and
password is same with the website login.
This GPS tracker can be used as car alarm, fleet management, driver management etc, it can be
used for tracking cars, company vehicles, taxis, trucks etc.
iPhone App Download QR Code
Android App Download QR Code
Manual(Word) Download QR Code
Manual(Pdf) Download QR Code
1
-
-
Advertisement
Table of Contents
Related Manuals for Carscop CCTR-831
Summary of Contents for Carscop CCTR-831
- Page 1 CCTR-831 OBD GPS Tracker Using Guide -201811 Welcome to use this OBD GPS tracker CCTR-831, This product can upload current location to website, display history tracking on website, it is very slim & anti-installation, connect the tracker to the vehicle OBD socket is OK, also shock sensor is built in to control power saving, shock & move alarm, built in rechargeable polymer battery 200mAH for power down alarm (tracker removed alarm), shock alarm, move alarm, over speed alarm, etc.
-
Page 2: Led Indicators
Product pictures: CCTR-831 OBD II Socket Indicator SIM Slot USB for Micro Card Maintain Specification: No installation. (Connect to car OBD is OK); Universal 4 GSM Band for Global; Wide Range Working Voltage: 9-40V DC, suitable for car or truck;... -
Page 3: Install Sim Card
Installation instruction 2. Power ON / OFF When power is OFF, connect the tracker to car OBD socket, the tracker will power on and search for GPS and GSM signal automatically. When the blue and yellow led lights are both ON,red LED flashes every 2 seconds, ... -
Page 4: How To Install
5-10minutes to find the GSM & GPS signal. CCTR-831 working voltage is 9V - 40V, it can be suit for 12V vehicle or 24V vehicle. the tracker will use the shock sensor to sense car moving to start uploading location to server, if the vehicle begin to move, the tracker will upload the location to sever immediately every 30 seconds, after the vehicle stop moving 2 minutes, the tracker will stop upload the location to server, the tracker will offline. -
Page 5: How To Use
4.3 Backup battery Tracker can work at least 0.5-1H with it’s own battery after car battery has been cut out. (If there is no battery inside, tracker is not capable to send alarm information). Your authorized number will get an alarm information when power has been cut out to inform you that your tracker might be removed. - Page 6 password and user information after logon, but can not change the user name, our administrator or dealer can change the user name by user request (ask your dealer to contact us), After logon, click the car you want check, the current location will display on the Google map, check the date and time and location is right or not, if it is correct, then you have installed the tracker and set the tracker properly, and it work well.
- Page 7 immediately.Note that due to static drift in GPS positioning, it is recommended that the xxx setting be more than 500.. 6.5 Power off alarm This tracker has power down alarm function, when the power supply is break, the tracker will notice the center number by making call 6 times, and also it will send SMS to center and slave center number to warning the car owner.
- Page 8 number"D101#",Command"D102#"(delete the first secondary number),command"D103#"(Delete the second secondary number). "D101#""D102#""D103#"are the fixed commands;. Reply"D10x OK"; 7.3 Check authorized number: Use your authorized number to send a message to the tracker"C10#" "C10#"is the fixed command. Reply "101#13987654321 102#13876543210 103#13765432101" 7.4 Change tracker password: This password is different with the platform login password, it is the password of the tracker, it is only used to control tracker by sending SMS or calling to the tracker.
- Page 9 from server,for example:"IP,d3.igps.info,58.64.155.133,8011"Means Domain name:d3.igps.info,Ip address:58.64.155.133,Port 8011,Reply"ip ok"if command is effected. 7.7 Check the tracker setting Send SMS "CXZT" to the tracker, the tracker will reply the setting of the tracker by SMS. If the tracker has no reply, please check the tracker work properly and confirm the SMS command is right.
-
Page 10: Troubleshooting
Platform User Guide Word Version Trouble Shooting The tracker auto power off: please confirm the tracker is plugged into the OBD socket properly and the power is ON. After power on the tracker, the tracker Blue & Orange LED should should keep on, if the LED flash please see the LED indicator description, and please confirm the SIM card has been installed properly, and the SIM card has enough charge, and the mobile phone can work well in that place. -
Page 11: Warranty
User Mobile Phone Tracker SIM card Date Year month Model CCTR-831 Serial Number Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, if you have any problem please contact us, thanks !
