4_Installation

4_1 Recommendation
Location of the AXIUM DOCK
Place the terminal on flat surface near an electric socket. The
terminal should be placed far from any very hot zones, protected
from vibrations, dust, damp and electromagnetic radiation (computer
screen, anti-theft barrier etc.).
Operating conditions
Ambiant temperature
Max relative humidity
Storage conditions
Ambiant temperature
Max relative humidity
Power supply
Electrical main network
External power supply
Securisation of your device
To undock your terminals below the terminal support please press the
dedicated button.
AXIUM DOCK
From 0°C to +40°C
85% at +40°C
From -20°C to +70°C
85% at +55°C
100 - 240VAC / 50-60Hz - Class VI
8V - 4A provided by Ingenico
12
900035196 R11 000 04/0319
