SET PANEL
t.pausa
T.
TRABALHO
Dip switch
di selezione
P pulsante
autoapprendimento
fcc
Comune finecorsa
fca
Trasf.
secondario
autotrasf.
Trasf.
primario
LIGAÇÕES NO TERMINAL DE BORNES
1-2 230VAC
3-4 FLASHING UNIT
5-6 24VAC
6-7 G.O. IND. LAMP
8 STOP
9 PHOTOCELLS
10 OPEN
11 CLOSE
12 STEP
13 PEDESTRIAN
14 COMMON
15-16 OUTPUT 2 CHANNEL
17-18 AERIAL
900CT-1A 900CT-1AR
+
+
Blocco
Mem.
Fus.
315ma
230Vac 50Mhz mains power supply
Output for flashing unit/courtesy lamp (selection between flashing unit
and courtesy lamp is set on the relative jumper) max 230Vac 25W for
flashing unit, max. 100W for courtesy lamp.
24Vac output for auxiliary power supply (photo, radio etc.) maximum
300mA
Output for door Open indicator lamp 24Vac max 2W
Input for stop command (emergency, external safety lock)
Input for safety devices (photocells, safety edges)
Input for open command
Input for close command
Input for sequential operating mode (open stop close stop)
Input for pedestrian command (see Special Functions)
Common contact for inputs
Output 2° channel (vers.CT-1AS)
Input for radio receiver aerial
Modulo radio
p.p.
ch.
ap.
foto
fca fcc
aut.
Fus.
6,3a
ap.
ch.
co.
cond.
(motore)
4
ant.
aaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaaa
GB
com.
ped.
pp
ch
ap
foto
Stop
c.a. Max 2w
24 Vac
300mA
lamp.
n
230 vac
50hz
l
