INSTALLATION AND OPERATING INSTRUCTIONS
30'-4"
18'-4"
27'-0"
11'-5"
Sedona: H: 11ft - 1"
SLIDE
2-4 Hrs
Two person
assembly
9405035
Rev 01/29/2016
S E D O N A - F 2 5 0 3 5
WARNING
Manufacturer contact information provided below.
OBSTACLE FREE SAFETY ZONE -30' 4" x 27' area requires Protective Surfacing. See page 3.
MAXIMUM VERTICAL FALL HEIGHT - 6' 9"
CAPACITY - 14 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.
RESIDENTIAL HOME USE ONLY. Not intended for public areas such as multi-unit residences, schools, churches,
nurseries, day cares or parks.
Cedar Summit
c/o ©Solowave Design L . P .
Mount Forest, ON Canada
N0G 2L0
www . c edarsummitplay . c om
support@cedarsummitplay . c om
Customer Service
1-877-817-5682 (toll free)
1-519-323-2258
To reduce the risk of serious injury or death, you must read and
follow these instructions. Keep and refer to these instructions
often and give them to any future owner of this play set.

Table of Contents

Warnings and Safe Play Instructions . . . . . . . . . . pg . 2
Protective Surfacing Guidelines . . . . . . . . . . . . . . . pg . 3
Instructions for Proper Maintenance . . . . . . . . . pg . 4
About Our Wood - Limited Warranty . . . . . . . . . pg . 5
Keys to Assembly Success . . . . . . . . . . . . . . . . . . pg . 6,7
Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg . 8-15
Step-By-Step Instructions . . . . . . . . . . . . . . . pg . 16-90
Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Last Page
FORT
10-14 Hrs
Two person
assembly
