Topcom Butler 4800Twin/Triple/Quattro
2

Display

Icon:
HS-x
3

Installation

3.1

Base

• Plug one end of the phone cable into the phone unit and the other end into the telephone
line wall socket.
• Connect the small plug of the AC adaptor to the phone and the other end of the adapter
cable to the electric socket.
6
Meaning:
You are online
New numbers in call list
Rechargeable battery level indicator
The antenna indicates the quality of reception.
The antenna blinks when the handset is out of range!
Microphone is muted
Memory records are being retrieved or set up
The keypad is locked
There are more digits on the left
There are more digits on the right
During hands free
When ring buzzer is turned off
There are new messages in your voice mail
During internal call
x = handset number
Power cable
Telephone cord
Topcom Butler 4800/Twin/Triple/Quattro
TEL.
SOCKET
