Summary of Contents for Moxa Technologies ioLogik E1261H
- Page 1 ioLogik E1200H Series User’s Manual Edition 2.2, April 2018 www.moxa.com/product © 2018 Moxa Inc. All rights reserved.
- Page 2 ioLogik E1200H Series User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2018 Moxa Inc. All rights reserved. Trademarks The MOXA logo is a registered trademark of Moxa Inc.
-
Page 3: Table Of Contents
Table of Contents Introduction ............................1-1 Product Model Information ........................1-2 Product Features ..........................1-2 Inside the Box ............................ 1-2 Product Specifications ......................... 1-3 Physical Dimensions ..........................1-3 Hardware Reference ..........................1-5 Panel Guide ..........................1-5 LED Indicators ..........................1-5 Initial Setup ............................ - Page 4 Network Port Numbers ........................B-1 Factory Defaults ..........................C-1 Pinouts .............................. D-1 FCC Interference Statement ......................E-1 European Community (CE) ........................ F-1...
-
Page 5: Introduction
Introduction The ioLogik E1200H series is a stand-alone remote Ethernet I/O server that can connect sensors and on/off switches for automation applications over Ethernet and IP-based networks. The following topics are covered in this chapter: Product Model Information Product Features ... -
Page 6: Product Model Information
E1200H Series Introduction Product Model Information Model Description ioLogik E1261H Remote Ethernet I/O with 2-port Ethernet switch and 12DIOs, 5AIs and 3RTDs, -40 to 75°C operating temperature ioLogik E1263H Remote Ethernet I/O with 2-port Ethernet switch and 24DIOs, 10AIs and 3RTDs -40 to 75°C operating temperature... -
Page 7: Product Specifications
E1200H Series Introduction Product Specifications NOTE The latest specifications for Moxa’s products can be found at https://www.moxa.com. Physical Dimensions ioLogik E1261H Unit = mm (inch) - Page 8 ioLogik E1200H Series Introduction ioLogik E1263H Unit = mm (inch)
-
Page 9: Hardware Reference
ioLogik E1200H Series Introduction Hardware Reference Panel Guide NOTE The reset button restarts the server and resets all settings to factory defaults. Remove the two screws and the aluminum plate on top of the aluminum housing, press and hold down the reset button for 5 sec. The factory defaults will be loaded once the Ready LED turns green again. -
Page 10: Initial Setup
Initial Setup This chapter describes how to install the ioLogik E1200H. The following topics are covered in this chapter: Hardware Installation Connecting the Power Grounding the ioLogik E1200H Connecting to the Network I/O Wiring Diagrams ... -
Page 11: Hardware Installation
ioLogik E1200H Series Initial Setup Hardware Installation Connecting the Power Connect the 12 to 48 VDC power line to the ioLogik E1200H’s terminal block on the top panel. If power is properly supplied, the Power LED will glow a solid amber color. ATTENTION Disconnect the power cord before installing or wiring your ioLogik E1200H. -
Page 12: I/O Wiring Diagrams
ioLogik E1200H Series Initial Setup I/O Wiring Diagrams... -
Page 13: Software Installation
ioLogik E1200H Series Initial Setup Software Installation ioSearch is a search utility that helps the user locate ioLogik E1200H devices on the local network. You may download the latest version of ioSearch from Moxa’s website. 1. Installing ioSearch: Download the ioSearch utility from Moxa’s website, double click the installation file, and then follow the installation wizard’s instructions to complete the installation. -
Page 14: Using The Web Console
Using the Web Console The ioLogik E1200H’s main configuration and management utility is the built-in web console, which can be used to configure a wide range of options. The following topics are covered in this chapter: Introduction to the Web Console ... -
Page 15: Introduction To The Web Console
ioLogik E1200H Series Using the Web Console Introduction to the Web Console The ioLogik E1200H web console is a browser-based configuration utility. When the ioLogik E1200H is connected to your network, you may enter the server’s IP address in your web browser to access the web console. -
Page 16: Overview
ioLogik E1200H Series Using the Web Console Overview The Overview page contains basic information about the ioLogik E1200H, including the model name, serial number, firmware version, MAC address, and current IP address. Most importantly, you can see the current I/O status by hitting the F5 key on the computer keyboard to refresh the page. -
Page 17: Network Settings
ioLogik E1200H Series Using the Web Console Network Settings General Settings On the General Settings page, you can assign a server name and location to assist you in differentiating between different ioLogik E1200H units. You may also configure the Modbus/TCP idle interval or enable the Communication Watchdog function. -
Page 18: User-Defined Modbus Addressing
ioLogik E1200H Series Using the Web Console User-defined Modbus Addressing The input and output address can be configured in a different format on a specific settings page. Check the “Enable User-defined Modbus Addressing” box, select the Modbus function, and then configure the start address of each item. -
Page 19: Aopc Server Settings
ioLogik E1200H Series Using the Web Console AOPC Server Settings Moxa’s Active OPC Server™ is a software package operated as an OPC driver of an HMI or SCADA system. It seamlessly connects Moxa’s ioLogik products to a wide variety of SCADA systems, including the most popular: Wonderware, Citect, and iFix. - Page 20 ioLogik E1200H Series Using the Web Console Click the “Submit” button and click the Save/Restart button on the next page. On the Create AOPC Tag page, click on the Create Tags button to push the tag configuration to Active OPC Server.
-
Page 21: I/O Settings
ioLogik E1200H Series Using the Web Console I/O Settings DI Channels The status of each DI (digital input) channel appears on the DI Channels page. You can also configure each channel’s digital input mode and parameters by clicking on the channel. DI channels can operate in DI mode or Event Counter mode. - Page 22 ioLogik E1200H Series Using the Web Console For Event Counter mode, configure “Lo to Hi, ” “Hi to Lo, ” or “Both” to trigger the counter. The counter should be set to either start, or stop. If it is in stop mode, the counter can be activated by the Modbus command. Make sure that the Counter Filter is not set to 0;...
-
Page 23: Do Channels
ioLogik E1200H Series Using the Web Console DO Channels On the DO Channels page, configure each DO (digital output) channel by clicking on the channel. DO Channels can operate in DO mode or Pulse Output mode. In DO mode, output is either on or off. In Pulse Output mode, configure the low width and high width to generate a square wave. -
Page 24: Ai Channels
ioLogik E1200H Series Using the Web Console AI Channels The current status of each AI (analog input) channel can be viewed on the AI Channels page. Click on a specific channel to enable or disable the AI channel by checking the “Enable AI Channel” box. Auto Scaling and Slope-intercept functions of the AI value can be defined on this page. -
Page 25: Ai Input Range
ioLogik E1200H Series Using the Web Console AI Input Range There are four modes in the analog input range: [0-10 V], [4-20 mA], [0-20 mA], [4-20 mA (burnout)], only [0-10 V] and [4-20 mA] supports peer to peer networking. Burnout mode can indicate if the current analog input has burnt out. The 4-20 mA burnout mode is defined in the diagram at the top of the following page: Users can define burnout values (BO, default 2mA) for selected ranges. - Page 26 ioLogik E1200H Series Using the Web Console The slope-intercept function is used to compensate when the measurement requires a slight adjustment. 3-13...
-
Page 27: Rtd Channels
ioLogik E1200H Series Using the Web Console RTD Channels The current status of each RTD (Resistance Temperature Detector) channel can be viewed on the RTD Channel page. Click on a specific channel to access the RTD channel settings. Select the “Enable RTD Channel” box and then select the sensor type that meets the physical attachment to the ioLogik E1200H. - Page 28 ioLogik E1200H Series Using the Web Console The ioLogik E1200H allows you to manually adjust the current temperature reading. In each channel configuration section, select the channel, apply the offset value, and click the “Submit” button to perform the task. 3-15...
-
Page 29: System Management
ioLogik E1200H Series Using the Web Console System Management IP Accessibility You can control network access to the ioLogik E1200H from the IP Accessibility page by only allowing access from specific IP addresses. When the accessible IP list is enabled, a host’s IP address must be listed in order to gain access to the ioLogik E1200H. -
Page 30: Network Connection
ioLogik E1200H Series Using the Web Console Network Connection TCP connections from other hosts appear on the Network Connection page. This information can assist you with managing your devices. Firmware Update Load new or updated firmware onto the ioLogik from the Firmware Update page. Import System Configuration Settings Import a configuration into the ioLogik server from the Import System Config page. -
Page 31: Export System Configuration Settings
ioLogik E1200H Series Using the Web Console Export System Configuration Settings On the Export System Config page, you can save the ioLogik’s configuration into a file for backup or import into another ioLogik server. RS-485 Configuration The RS-485 port is used to communicate with other RS-485 devices or to link to another ioLogik RS-485 I/O server. -
Page 32: Load Factory Defaults
ioLogik E1200H Series Using the Web Console Load Factory Defaults This function will reset all of the ioLogik E1200H’s settings to the factory default values. All previous settings, including the console password will be lost. Save/Restart If you change the configuration, do not forget to reboot the system. 3-19... -
Page 33: Using Iosearch
Using ioSearch This chapter describes ioSearch, which is used to search for and locate ioLogik E1200H units. The following topics are covered in this chapter: Introduction to ioSearch ioSearch Main Screen Main Screen Overview Main Items ... -
Page 34: Introduction To Iosearch
ioLogik E1200H Series Using ioSearch Introduction to ioSearch ioSearch is for locating or searching for an Logik E1200H on the physical network. The following functions are supported by the ioSearch utility. • Search for and locate ioLogik E1200H units. • IP address configuration. -
Page 35: Main Items
ioLogik E1200H Series Using ioSearch Main Items System Several operations are possible from the System menu. Auto Scan Active Ethernet I/O Servers will search for ioLogik servers on the network. When connecting for the first time or recovering from a network disconnection, you can use this command to find I/O servers that are on the network. -
Page 36: Sort
ioLogik E1200H Series Using ioSearch Sort The Sort menu allows the server list in the navigation panel to be sorted by ioLogik connection and server (model). Quick Links Quick links are provided to search for I/O servers on the network and sort the server list. Automatically search the local network Sort by ioLogik E1200H’s IP address (connection) Sort by ioLogik E1200H model... -
Page 37: Main Function
ioLogik E1200H Series Using ioSearch Main Function Right click on a particular ioLogik E1200H to view the ioSearch function menu. Locate The locate function helps users find a dedicated ioLogik on the network. When this function is triggered, the ready LED on the selected unit will start to blink indicating its location. Firmware Upgrade The ioLogik E1200H supports a remote firmware upgrade function. -
Page 38: Unlock
ioLogik E1200H Series Using ioSearch Unlock If an ioLogik E1200H is password protected, unlock the ioLogik E1200H by entering the password before using any of the functions. Import Select this command to reload a configuration that was exported to a text file. Importing one configuration file to multiple ioLogik E1200H units (same model) is allowed. -
Page 39: Change Ip Address
ioLogik E1200H Series Using ioSearch Change IP Address The Change IP Address function can be used to directly modify the IP Address, especially for first time installation. Changing the IP address for multiple ioLogik E1200H’s is allowed. Select the ioLogik E1200H and then right click to process this function. -
Page 40: Restart System
ioLogik E1200H Series Using ioSearch After the “Advance” button is clicked, a window will pop up to allow users to use ioSearch to set the IP address by MAC address. ioSearch will automatically set sequential IP addresses on the selected devices, with the subnet mask and gateway set to the same value. -
Page 41: Mass Deployment (Export)
ioLogik E1200H Series Using ioSearch Mass Deployment (export) Users can export E1200H series module information via ioSearch. The export file format will be E1200H_Series_List. -
Page 42: Modbus/Tcp Default Address Mappings
Modbus/TCP Default Address Mappings The following topics are covered in this appendix: E1261H Modbus Mapping E1263H Modbus Mapping... -
Page 43: E1261H Modbus Mapping
ioLogik E1200H Series Modbus/TCP Default Address Mappings NOTE The Modbus/TCP ID of the ioLogik E1200H is set to “1” by default. E1261H Modbus Mapping Fixed + Dynamic Default addresses Func Ref. Address Channel Data type R/W Description Code Address 1 or 101 0xxxx 0x0000 1 bit... - Page 44 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 00037 0x0024 1 bit CH4 DO Pulse Operate Status 0: Off 1: On 00038 0x0025 1 bit CH5 DO Pulse Operate Status 0: Off 1: On 00039 0x0026 1 bit CH6 DO Pulse Operate Status 0: Off 1: On 00040...
- Page 45 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 00771 0x0302 1 bit DIO2 1: output DO mode 0: input DI mode 00772 0x0303 1 bit DIO3 1: output DO mode 0: input DI mode 00773 0x0304 1 bit DIO4 1: output DO mode...
- Page 46 ioLogik E1200H Series Modbus/TCP Default Address Mappings 3xxxx Read only Registers (Support function 4) Reference Address Data Type Description DI Channel 30001 0x0000 1 word CH0 DI WordValue, 0=OFF, 1=ON (Read only) 30002 0x0001 1 word CH1 DI WordValue, 0=OFF, 1=ON (Read only) 30003 0x0002 1 word...
- Page 47 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 0: Normal 1: Burn Out 2: Over Range 30562 0x0231 1 word Read AI 1 Current Mode Status 0: Normal 1: Burn Out 2: Over Range 30563 0x0232 1 word Read AI 2 Current Mode Status 0: Normal...
- Page 48 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description Bit0 = Ch0 DO Value (0=OFF, 1=ON) … Bit15 = Ch15 DO Value (0=OFF, 1=ON) DI Channel 40257 0x0100 1 word CH0 DI Counter Operate Status 0: Stop 1: Start(R/W) 40258 0x0101 1 word...
-
Page 49: E1263H Modbus Mapping
ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 1=PT100, 4=PT1000 41555 0x0612 1 word CH2 RTD Sensor Type 1=PT100, 4=PT1000 E1263H Modbus Mapping Fixed + Dynamic Default addresses Func Reference Address Channel Data Type Description Code 1 or 101 0xxxx 0x0000... - Page 50 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 00016 0x000F 1 bit CH15 DO Value 0: Off 1: On 00017 0x0010 1 bit CH16 DO Value 0: Off 1: On 00018 0x0011 1 bit CH17 DO Value 0: Off 1: On 00019 0x0012 1 bit...
- Page 51 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 00295 0x0126 1 bit CH6 DI Clear Count Value Read Always return:0 Write: 1 : Clear counter value 0 : Return illegal data value(0x03) 00296 0x0127 1 bit CH7 DI Clear Count Value Read Always return:0...
- Page 52 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 00784 0x030F 1 bit DIO15 1: output DO mode 0: input DI mode 00785 0x0310 1 bit DIO16 1: output DO mode 0: input DI mode 00786 0x0311 1 bit DIO17 1: output DO mode...
- Page 53 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 10021 0x0014 1 bit CH20 DI Value, 0=OFF, 1=ON (Read only) 10022 0x0015 1 bit CH21 DI Value, 0=OFF, 1=ON (Read only) 10023 0x0016 1 bit CH22 DI Value, 0=OFF, 1=ON (Read only) 10024 0x0017 1 bit...
- Page 54 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 30065 0x0040 1 word DI Value (Ch0~15) Bit0 = Ch0 DI Value (0=OFF, 1=ON) Bit15 = Ch15 DI Value (0=OFF, 1=ON) 30066 0x0041 1 word DI Value (Ch16~23) Bit0 = Ch16 DI Value (0=OFF, 1=ON) …...
- Page 55 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 30564 0x0233 1 word Read AI 3 Current Mode Status 0: Normal 1: Burn Out 2: Over Range 30565 0x0234 1 word Read AI 4 Current Mode Status 0: Normal 1: Burn Out 2: Over Range...
- Page 56 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 40013 0x000C 1 word CH12 DO Value 0: Off 1: On 40014 0x000D 1 word CH13 DO Value 0: Off 1: On 40015 0x000E 1 word CH14 DO Value 0: Off 1: On 40016 0x000F 1 word...
- Page 57 ioLogik E1200H Series Modbus/TCP Default Address Mappings Reference Address Data Type Description 0 : Return illegal data value(0x03) 40293 0x0124 1 word CH4 DI Clear Count Value Read Always return:0 Write: 1 : Clear counter value 0 : Return illegal data value(0x03) 40294 0x0125 1 word...
-
Page 58: Network Port Numbers
Network Port Numbers ioLogik E1200H Network Port Usage Port Type Usage Web console service Modbus/TCP communication BOOTP/DHCP 4800 Auto search Export/import configuration file 9900 Active OPC Server 9500 Active OPC Server... -
Page 59: Factory Defaults
Factory Defaults ioLogik E1200H series products are configured with the following factory defaults: Default IP address 192.168.127.254 Default Netmask 255.255.255.0 Default Gateway 0.0.0.0 Communication watchdog Disable Modbus/TCP Alive Check Modbus/TCP Timeout Interval 60 sec DI Mode Filter time 100 ms Trigger for counter Lo to Hi Counter status... -
Page 60: Pinouts
Pinouts Terminal Block Pin Assignments... -
Page 61: Fcc Interference Statement
FCC Interference Statement Federal Communication Commission Warning! This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 62: European Community (Ce
European Community (CE) This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures.
