Bastion Gas Fire Table
Model No. GM142-157
CARBON MONOXIDE HAZARD
WARNING:
Do not store or use gasoline, or other
flammable vapors and liquids, in the
vicinity of this or any other appliance.
An LPG Cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Retain these instructions for future use.
This appliance can
produce carbon
monoxide which has
no odour.
Using it in an enclosed
space, eg. boat,
caravan, tent, car,
campervan or house,
may cause death.
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odour.
Using it in an enclosed space, eg. boat,
caravan, tent, car, campervan or
house, may cause death.
CARBON MONOXIDE HAZARD
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
WARNING:
For Outdoor Use Only
CARBON M
This appliance can
produce carbon
monoxide which has
no odor.
Using it in an
enclosed space can
kill you.
Advertisement
Table of Contents
Related Manuals for Gasmate GM142-157
Summary of Contents for Gasmate GM142-157
- Page 1 Bastion Gas Fire Table Model No. GM142-157 CARBON M CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odour. Using it in an enclosed space, eg. boat, caravan, tent, car, campervan or house, may cause death. CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odour.
-
Page 2: Installation
Installation, Operation and Maintenance Instructions INSTALLATION 3. Proper clearance from combustible materials must be Important Safety Rules: maintained at all times. The minimum clearances are This appliance must only be used in a well ventilated as follows: area. 1. This appliance shall not be installed or used indoors, Minimum Clearance from Combustibles: in buildings, garages or any other enclosed area. - Page 3 7. The hose assembly should be properly located out of 5. Reconnect the regulator to the gas cylinder. pathways where people may trip over it. The hose 6. Leak test the connection using a soapy water solution. must be protected from contact with hot or sharp Ensure no bubbles appear before proceeding.
-
Page 4: General Assembly
GENERAL ASSEMBLY Connecting & Disconnecting to Gas Source 3. When connecting the hose to the cylinder tighten the nut to a positive stop by hand. IMPORTANT: Before connecting and 4. Open cylinder valve fully. If a leak can be heard at disconnecting appliance to gas source, make either end of the hose, turn cylinder off and tighten sure control knob is in ‘OFF’... -
Page 5: Parts List
PARTS LIST Part # Description Picture Part # Description Picture Table Top Door Frame Door Knob Side Panel Base Frame Gas Valve Panel Ceramic Tile Back Right Leg Cushion Pad Lava Rock Front Right Leg Hardware# Dimensions Picture M5 x 12 M6 x 12 Back Left Leg M5 x 20... - Page 6 ASSEMBLY INSTRUCTIONS Your fire table must be installed on a flat, stable surface, Note: Remove any transit protection material. away from any combustible materials or construction. Tools required: Get a friend to help you put your gas fire table together. •...
- Page 7 ASSEMBLY INSTRUCTIONS STEP 3 Attach one side panel (2) to front left leg (8) and back left leg (7) with 6 M5x12 bolts (A). x 12 Bolt Assembly M5 x 12 Bolt M5 x 20 Bolt M6 x 12 Bolt ST4.2 x 9.5 Bolt Qty.
- Page 8 ASSEMBLY INSTRUCTIONS STEP 5 Attach one side panel (2) to back right leg (4) and front right leg (5) with 6 M5x12 bolts (A). x 12 Bolt Assembly M5 x 12 Bolt M5 x 20 Bolt M6 x 12 Bolt ST4.2 x 9.5 Bolt Qty.
- Page 9 ASSEMBLY INSTRUCTIONS STEP 7 Screw door knob (10) to door (9). STEP 8 Attach door (9) to front left leg (8) assembly with 4 ST4.2x9.5 bolts (D) Note: With the help of a friend, turn the gas fire table into upright position after this step is finished.
- Page 10 ASSEMBLY INSTRUCTIONS STEP 9 Peel and stick the 16 cushion pads (13) on to the table top frame (1). Note: Before applying the adhesive cushion pads, be sure to wipe down the metal surface and make sure it is free of any dust or debris.
- Page 11 ASSEMBLY INSTRUCTIONS STEP 11 Put the lava rocks (14) into the burning area, in the middle of the table top. Place the cover lid (6) onto the table top when the gas fire table is not in use. Note: To avoid ignition failure, do not cover the flame orifice with lava rocks (see page 13).
- Page 12 ASSEMBLY INSTRUCTIONS GAS CONNECTION INSTRUCTIONS ASSEMBLY INSTRUCTIONS STEP 11 STEP 12 STEP 13 Step 1 Step 4 Turn on the gas cylinder ensuring that the control knob Ensure cylinder valve is in its full off position. Check Use a solution of soapy water (dishwashing liquid and Use a solution of soapy water (dishwashing liquid and water STEP 11 Inside of the LPG compartment the gas hose and...
-
Page 13: Gas Connection Instructions
GAS CONNECTION INSTRUCTIONS Step 5c: STEP 14c The connection is gas tight when no bubbles grow around repeat The connection is gas tight when no bubbles grow the gas connection. around the gas connection. Step 6 Place all lava rocks evenly in the fire table on the top of the appliance. -
Page 14: Lighting Instructions
TEST FIRING APPLIANCE STORAGE & MAINTENANCE Test fire appliance, following the lighting instructions found on the appliance. Leak test all gas connections with To obtain the best performance from your fire table, you soapy water. Soap bubbles indicate gas leakage. must perform the following storage and maintenance DO NOT use a flame to test for gas leaks. -
Page 15: Troubleshooting
TROUBLE SHOOTING Problem: Condition: Solution suggested: Igniter pin and burner are wet. Wipe dry with a cloth. Igniter pin cracked or broken. Contact retailer where purchased for replacement part. Appliance won’t Reconnect wire to the igniter box light Electrode wire is loose or located inside the table base behind disconnected. - Page 16 Limited Warranty OUTDOOR HEATER RANGE Aber Living warrants the purchaser of this product against defects in workmanship and material, for a period of up to 12 months from the date of purchase. The warranty is non-transferable and becomes void if used for commercial or rental purposes. Warranty and purchase receipt of this product are to be retained as proof of purchase and must be presented if making a claim under the terms of the Aber Living Warranty.
