3. Hand the controller by the hooks at the top of the DIN rail channel on the back of the controller, and position the
controller snugly against the DIN rail.
4. Push the bottom mounting clips inward (up) to secure the controller on the DIN rail tracks.
To remove the controller from the DIN rail, pull the bottom mounting clips out to the extended position and carefully
lift the controller off the DIN rail.
Wiring
Risk of Electric Shock: Disconnect the power supply before making electrical connections to avoid electric
shock.
Mise En Garde: Risque de décharge électrique: Débrancher l'alimentation avant de réaliser tout raccordement
électrique afin d'éviter tout risque de décharge électrique.
Risk of Property Damage: Do not apply power to the system before checking all wiring connections. Short
circuited or improperly connected wires may result in permanent damage to the equipment.
Mise En Garde: Risque de dégâts matériels: Ne pas mettre le système sous tension avant d'avoir vérifié tous
les raccords de câblage. Des fils formant un court-circuit ou connectés de façon incorrecte risquent
d'endommager irrémédiablement l'équipement.
IMPORTANT: Do not exceed the controller electrical ratings. Exceeding controller electrical ratings can result
in permanent damage to the controller and void any warranty.
IMPORTANT: Use copper conductors only. Make all wiring in accordance with local, national, and regional
regulations.
IMPORTANT: Electrostatic discharge can damage controller components. Use proper electrostatic discharge
precautions during installation, setup, and servicing to avoid damaging the controller.
For detailed information on configuring and wiring an MS/TP Bus, FC Bus, and SA Bus, refer to the MS/TP
Communications Bus Technical Bulletin (LIT-12011034).

Hard-Wired Installation

To install an FEU16 for hard-wired operation, perform the steps that follow. See
locations.
Input/Output Terminals
Terminate input/output point wiring at the controller per engineering drawings.
SA Bus Terminal Block and Sensor Port
Wire Network Sensors and other devices to the Sensor Actuator (SA) Bus terminal block
(RJ-12 modular jack) for sensors.
Note: The FEU16 controller should be at one end of the SA Bus daisy chain. If multiple Input/Output Modules
(IOMs) are used, set the End-of-Line (EOL) switch on the last IOM.
FEU16x0 Field Equipment Controller Installation Instructions
Figure 1
4
for jack and terminal block
(Figure 3) or Sensor port
