Page 2: Exploded View And Parts List
EXPLODED-VIEW & PARTS LIST：... - Page 3 NAME QUANTITY SPEC PEDAL JD-301（9/16"） END CAP1 80*40*1.5 CARRIAGE BOLT GB/T 12-1988 M8*52 WELDING REAR STABILIZER FLAT WASHER GB/T 95-2002 GB/T 802-1988 M8 DOMED NUT (H=16mm) SPRING ADJUSTMENT KNOB φ50*82 (M16*1.5) PLASTIC SLEEVE 1 70*30*1.5 KNOB COVER 177X142X187 VERTICAL SEAT POST WELDING END CAP 2 70*30*1.5...
- Page 4 NAME QUANTITY SPEC SCREW 1 GB/T 845-1985 ST4.2*19 SCREW 2 GB/T 15856.1-2002 ST4.2X19 SCREW 3 GB/845-85 ST4.8X13 OUTER CHAIN COVER 654*263*49 (507g) LITTLE CHAIN COVER 108*37*3 (7g) AXIS φ20*162 LONG FIXING TUBE φ25*φ20.5*41 SHORT FIXING TUBE φ25*φ20.5*9 INNER CHAIN COVER 451*260*2 (250g) BELT 5PK53...
-
Page 5: Assembly Instruction
ASSEMBLY INSTRUCTION: 1.PREPARATION: A. Before assembling make sure that you will have enough space around the item. B. Use the present tooling for assembling. C. Before assembling please check whether all needed parts are available (at the above of this instruction sheet you will find an explosion drawing with all single parts (marked with numbers) which this item consists of. - Page 6 FIG.3: Slide the Handlebar Post (pt.17) into the handlebar post housing on the main frame(pt.16). You will have to slacken the knurled section of the L Shape Knob (pt.19) and pull the knob back and then select the desired height. Release the knob and retighten the knurled portion.
- Page 7 A.) Adjusting the Tension: Increasing or decreasing the tension allows you to add variety to your workout sessions by adjusting the resistance level of the bike. To increase tension and increase resistance (requiring more strength to pedal), turn the Emergency Brake &...
- Page 8 GARLANDO SPA Via Regione Piemonte, 32 - Zona Industriale D1 15068 - Pozzolo Formigaro (AL) - Italy www.toorx.it - info@toorx.it...
