Summary of Contents for TOORX BRXR COMFORT
- Page 1 INSTRUCTION...
- Page 2 Hardware Description Drawing Allen screw M8*50 Curve washerФ8*Ф20*1.5 Allen screw M8*16 Carriage bolt M8*40 Domed nut M8 Flat washer Ф17*Ф8.5 Foot pad Quick release knob Allen key Allen wrench...
-
Page 3: Exploded Diagram
EXPLODED DIAGRAM... - Page 4 EXPLODED DIAGRAM...
-
Page 5: Parts List
PARTS LIST Description Description Main Frame Pedal R Allen Bolt M8*50 Pedal L Front Stabilizer Flat washerФ17*Ф8.5 Curve washerФ8 Foot pad End cap for front stabilizer R Seat post End cap for front stabilizer L Sliding tube Rear stabilizer Quick release knob End cap for rear stabilizer Cushion post Front post... -
Page 6: Pre-Assembly Check List
PRE-ASSEMBLY CHECK LIST NO:1 NO:9 NO:40 NO:43 NO:3 NO:7 NO:13 NO:10 NO:45 NO:44 NO:12 NO:11 NO:37 NO:36 NO:46 NO:41 Description Main Frame Front Stabilizer Rear Stabilizer Front post computer Handlebar R Handlebar L Back handlebar Pedal Right Pedal Left Seat post Sliding tube Cushion post Cushion... -
Page 7: Assembly Instruction
ASSEMBLY INSTRUCTION Step 1: Attach the front stabilizer (3) to the main frame (1),secure using two allen bolts (2)and two curve washers (4) Step 2: Connect the lower hand pulse wire (23) to the middle hand pulse wire (22). ... - Page 8 Step 3: Place the front post cover(46) into front post(9) first. Adjust the tension cable (32) to the level eight and slot into the lower tension cable (33). Connect the extension sensor wire (34) to the lower sensor wire (35).Connect the upper hand pulse wire(16) to the middle hand pulse wire (22).
- Page 9 Step 5: Connect the lower hand pulse wire (23) to the hand pulse wire (24). Attach the back handlebar (13) to the cushion post (43), secure using two sets of curve washer (4),carriage bolts(28) and domed nut(29). Attach the cushion (44) to the cushion post (43), secure using four allen bolts (21).
-
Page 10: Computer Instructions
COMPUTER INSTRUCTIONS FUNCTIONAL BUTTONS: MODE - Push down for selecting functions. SET -To set the values of time、distance、calories and pulse when not in scan mode. RESET - Push down for resetting time、distance and calories. FUNCTION AND OPERATIONS: 1.SCAN: Press “MODE” button until “SCAN” appears, monitor will rotate through all the 5 functions: Time、speed、distance、calorie ODO and pulse. -
Page 11: Specifications
SPECIFICATIONS: AUTO SCAN Every 4 seconds TIME 00:00’~99:59’ CURRENT The maximum signal can be pickup is SPEED 99.9KM/H FUNCTION TRIP 0.00~99.99KM or 0.00~9999KM DISTANCE CALORIES 0.1~999.9kCAL 0.1~999.9KM or 1 ~ 9999KM PULSE RATE 40~206BPM BATTERY TYPE 2pcs of SIZE –AA or UM –3 OPERATING TEMPERATURE 0°C ~ +40°C STORAGE TEMPERATURE... - Page 12 GARLANDO SPA Via Regione Piemonte, 32 - Zona Industriale D1 15068 - Pozzolo Formigaro (AL) - Italy www.toorx.it - info@toorx.it...
