- Page 1 IP and PoE+ over Coax Solution eBridge1600F - 16-Port Managed EoC Receiver with Integral PoE+ Switch Installation Guide More than just power. Rev. 091118...
- Page 2 Overview: Altronix eBridge1600F is an all-in-one head-end solution for upgrading coax to IP that combines a PoE+ switch and EoC Receiver into a single integrated unit for upgrading existing coax infrastructure and deploying the latest IP devices. This 16-Port Managed EoC Receiver with Integral PoE+ switch provides 30W full power per port (500W max).
-
Page 3: Installation Instructions
Installation Instructions: Wiring methods shall be in accordance with the National Fig. 1a Fig. 1b Electrical Code/NFPA 70/ANSI, and with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application. eBridge1600F is not intended to be connected to outside plant leads and should be installed indoors within the pro- tected premises. - Page 4 eBridge1600F Fig. 2 eBridge100ST eBridge100ST Coax (300m) Mini Transceiver Mini Transceiver Data & PoE 15W/30W 115/230VAC Stand-by Input Batteries eBridge1600F- Rear Panel eBridge1600F- Front Panel To Fiber LAN/WAN Switch eBridge100TM Fig. 3a Yellow LED indicates PoE transmitted to Camera/Device Coax from Structured Cable to eBridge1600F Camera/Device...
-
Page 5: Technical Specifications
Technical Specifications: Parameter Description Connections BNC for Coax link. RJ45 for ethernet link. SFP Fiber Port. Input power 115VAC, 60Hz, 6A or 230VAC, 50/60Hz, 3.2A. requirements eBridge1600F: Power LED: 115/230VAC is present. Blue LED (near BNC) - Coax link connection. Yellow and Green LED (RJ45) - IP Link status, 100Base-T/active. -
Page 6: Factory Default Settings
Configuring eBridge1600F for Network Connection –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Please be sure to visit altronix.com for latest firmware and installation instructions –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Factory Default Settings • IP Address: 192.168.168.168 • User Name: admin • Password: admin 1. Set the static IP address for the laptop to be used for programming to the same network IP address as the eBridge1600F. -
Page 7: Rack Mount Installation
Mounting Options: Rack Mount Installation 1. Remove and discard factory installed screws from both sides of rack chassis (Fig. 4a). 2. Install mounting brackets (A) on the left and right side of rack chassis using the four (4) flat head screws (B) (included) (Fig. - Page 8 1.625" 42mm Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIeBridge1600F A08S - 8 -...
