Altronix Pace1PRD Installation Manual

Pace1PRD
IP and Hi-PoE Receiver over extended distance CAT5e
Pace1PRD is a long range Ethernet receiver which transmits data at 100mbps full duplex and power
via a Cat5e or higher cable. The Pace1PRD receiver is powered via Altronix NetWay1D midspan
injector. The receiver passes the Hi-PoE (60W) power over the cable to the eBridge200WPM
transceiver which in turn passes this power to an enabled IP camera/device. These plug and play
units facilitate cost effective solutions for IP devices that need to be installed at distances greater
than 100m.
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
Input:
• Powered by NetWay1D (60W).
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or 1 pair UTP
structured cable.
• Distance: up to 500m (1,500 ft.).
• Speed: 10/100BaseT, half/full duplex,
auto negotiation.
• Throughput is rated to pass 100mbps of
data at distances up to 1,500 ft. With
proper headend equipment this supports
Megapixel, HD720, HD1080.
CAT5e or Higher:
• Distance: up to 1,500 ft. @ 100mbps (see
Cable Type, Total Device Power, Data and
Power Distance, pg. 3).
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and
with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or
Recognized wire suitable for the application.. Pace1PRD is intended for indoor use only.
1. Pace1PRD installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the unit's
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in proximity to ethernet
switch/network, NVR or video server.
b. Connect structured cable from NetWay1D to RJ45 jack marked [PoE Input] (Fig. 2, pg. 3).
c. CAT5e or higher: Connect CAT5e or higher cable to connector marked [RJ45 OUT]
(Fig. 2, pg. 3).
2. eBridge200WPM connections:
a. Connect Cat5e from Pace1PRD (60W) to connector marked [CAT INPUT] (Fig. 2, pg. 3)
b. Select input power SW3 on switch marked [60W CAT, 30W CAT or 60W COAX] (Fig. 2, pg. 3).
c. Connect structured cable from one (1) 60W camera/device to RJ45 jack marked [Port 1] or
connect two (2) individual structured cables from two (2) 30W cameras/devices to RJ45
jacks marked [Port 1 & Port 2] (Fig. 2, pg. 3).
Pace1PRD
All manuals and user guides at all-guides.com
Overview:
Features:
LED Indicators:
• Green - PoE ON (by respective RJ45 jack).
• Yellow and Green LED IP Link status,
Environmental:
• Operating Temperature Pace1PRM:
• Storage Temperature:
• Humidity: 20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
Applications:
• Extend Network link distance in an
• Works with Megapixel, HD720, HD1080
Mechanical:
• Dimensions (W x L x H approx.):
Installation Instructions:
Installation Guide
10/100Base-T/active.
-- 4ºF to 120.2ºF (-- 20ºC to +49ºC).
-- 22º to 158ºF (-- 30º to +70ºC) Storage.
non-PoE cameras/devices.
industrial environment (see note, pg. 2).
and VGA (SD) cameras (see note, pg. 2).
3.5" x 3.5" x 1"
(88.89mm x 88.89mm x 25.4mm)
Rev. 011615
I.T.E. 43KC
- 1 -
