Altronix eBridge Plus 1600F Installation Manual page 8

eBridge1600F Enclosure Dimensions (H x W x D approximate):
0.75"
19.05mm
8.5"
216mm
1.625"
8
42mm
16
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIeBridge1600F
- 8 -
1.625" x 19.125" x 8.5" (42mm x 486mm x 216mm)
7 6 5 4 3
15 14 13 12 11
19.125"
486mm
17.625"
447.7mm
2 1
10 9
A08S
1Gb SFP
MEMBER
eBridge1600F
