Misc Menu – Security
Press any menu title
button at any time
to "escape" without
making changes.
To get here from the Main Menu,
• Security Lockout
Instruction message appears here >
Use option selections with buttons >
Figure 3-14. Misc/Security menu (shown with Normal Mode selected)
_______ The master password to be used for emergencies is 1000.
www.camboard.de
3-15
CAMBOARD Electronics
press:
• Misc
Security Lockout
The menu shown above comes up after selecting Security Lockout from the Misc
Menu on Page 3-13 – after the correct password has been entered.
Use the scroll buttons or the speed knob to select one of the four options from
this menu. This example shows Normal Mode. Press Take to display the menu.
Normal Mode
This is the mode the FPC 1000 uses to operate when not in one of the other
special modes. Select this mode to return to default operation.
Executive Mode
Select this mode to prevent any changes from being made from the FPC 1000.
The panel may be used to view any settings but changes (adjustments) are not
allowed.
FPC Lock Out
Select this mode to prevent any menu from being accessed. In Lockout Mode,
pressing any FPC button brings up a menu that requests a password. You must
enter the correct password to access that menu.
Set Password
Use this menu to change the password. You must know the current password to
change it.
Tel. 07131 911201
Matrix 3200/6400 Series Switchers • FPC 1000 • User's Manual • Extron
Fax 07131 911203
Using the FPC 1000 Front Panel Controller • Chapter 3
Mode
