Status or Setup Value:
input status, output status
value for the displayed input sensor, output
and/or setup parameter.
a different Parameter Value when the value
is flashing. (Here, 100 = 100%.)
Status or Setup Identifier:
unit of measurement, output, sensor number,
or
setup parameter for the displayed Status or
Setup Value. (Here, the Setup Identifier
represents % Output at Setpoint.)
M
Menu Button: Press
to move through the
sensor and output setup start screens.
When moving through the status or setup
M
screens, press
to return to the status start
screen or set up start screen.
Up and Down Buttons: Press
a different value for any flashing value in the
Setup Value field. In the Main/Default (Sensor
Status) screen, press and hold both
for 5 seconds to access the Setup Start screens.
Figure 4: System 450 Control Module Output Relay LEDs, LCD, Four-Button Touch Pad User Interface
Setup and Adjustments
System 450 Component Requirements
A System 450 control system consists of one control
module, one to three control sensor inputs, and one to
ten outputs that provide On/Off control and/or analog
control. Figure 3 shows an example System 450
module assembly with two input sensors and three
outputs (two relay outputs and one analog output).
Setting up a System 450 Module Assembly
To set up a System 450 module assembly:
1. Determine the controlled conditions, sensor types,
and value ranges required for your application, and
select the appropriate System 450 sensor types.
2. Determine the number and type (relay or analog) of
outputs required to control your application, and
select the appropriate System 450 control module
and expansion modules to provide the outputs.
3. Assemble the control and expansion modules in
the proper order, starting with the control module
on the left.
Note: If you use a C450YNN-1 power module, it
must be plugged into the control module. Plug in
any expansion modules (for your control system) to
the right of the power module.
4. Apply supply power to the module assembly.
4
System 450™ Series Control Modules with Relay Outputs Installation Instructions
Displays the current
or
setup parameter
Press
or
to
select
Displays the
OSP
or
to select
and
Light-Emitting Diode (LED): Green LEDs
on Relay Control Module and Relay
Expansion Modules (only) indicates if the
associated Relay Output is On or Off.
100
Output Number: Displays a numerical
value that identifies the Output associated
with the Status or Setup Value shown
OSP
4
on the screen. Output Numbers are
automatically determined by the outputs'
physical positions (left to right) in the
module assembly. (Here, 4 = Output 4.)
Control Ramp Icon: Displays whether an
Analog Output (only) is set as direct-acting
M
or reverse acting, and whether the output
signal strength is at minimum or maximum
when the sensed property is at Setpoint.
The Control Ramp icon displayed is
determined by the Output's SP, EP, OSP,
and OEP setup values.
Next Button: In the Main/Default screens,
press
screens. In a setup screen, press
the (flashing) Setup Value and go to the
next setup screen.
You can now set up your control system in the
System 450 reset control module UI.
Note: After you power on your module assembly, you
can set up your control system in the control module UI
before wiring the sensors or outputs to your assembly.
Setting Active/Passive Sensor Jumpers
Before putting your System 450 reset control system
into operation, you must set up each sensor in your
system as either passive or active by positioning the
jumper on the terminal pins on the terminal block
located below the sensor terminal block. See Figure 3.
Temperature sensors are passive (2-wire) sensors and
the corresponding jumpers must be positioned across
both pins. Humidity and pressure transducers are
active (3-wire) sensors and corresponding jumpers
must be positioned on one pin (or removed
completely). Figure 5 shows the jumper positions for
the System 450 example shown in Figure 3.
Sensor 1:
(or removed) sets Sn-1 to Active (Pressure).
Sensor 2:
pins sets Sn-2 to Passive (Temperature).
Sn-1
Sn-2
Sensor 3:
Sn-3
pins sets Sn-3 to Passive (Temperature).
Figure 5: Active/Passive Sensor Terminal Pin
Block Set up for Example in Figure 3
to scroll through the system status
to save
Jumper positioned on one pin
Jumper positioned across two
Jumper positioned across two
