Table 5: System 450 Relay Output Setup Screen Information and Procedures (Continued)
LCD Screen Name, Description/Function, User Action, and Example
Minimum Relay ON Time Selection Screen: Minimum ON Time range is 0 to 300 seconds.
0
5. Press
Relay ON value, then press
ONT
1
Selection Screen.
Screen example shows 0 (zero) seconds selected for the minimum ON-Time for Output 1.
Minimum Relay OFF Time Selection Screen: Minimum OFF Time range is 0 to 300 seconds.
120
6. Press
Relay OFF value. Press
OFFT
1
screen.
Screen example shows 120 seconds selected for the minimum OFF-Time for Output 1.
Sensor Failure Mode Selection Screen: Select this output's mode of operation if the referenced sensor
OFF
or sensor wiring fails. The output operates in the selected mode until the failure is remedied.
Sensor Failure mode selections for Relay Outputs include:
SNF
1
• ON output relay remains On during sensor failure.
• OFF output relay remains Off during sensor failure.
7. Press
Screen example shows OFF sensor failure mode selected for Output 1. This output relay is Off if the
referenced sensor or sensor wiring fails.
Edit Sensor Screen: This screen displays the sensor that this output currently references. Typically, no
Sn-2
action is taken in this screen. But if you need to change the sensor that this output references, you
can select a different sensor for this output in this screen.
SENS
Note: Changing the sensor that an output references to a sensor with a different Sensor Type changes
the default setup values for the output, and requires setting up the output again.
8. To change this output's sensor, Press
reference. After you select a different sensor for this output, press
Selection screen (Step 3 above) and repeat the output relay setup procedure for this output
and the new Sensor Type values associated with the new sensor selection.
If you do not need to change this output's sensor, simply press
selection and return to the Relay Output Setup Start screen.
This Relay Output is now set up in the System 450 UI.
Screen example shows input Sensor 2 selected for Output 1 (Output 1 references Sensor 2).
Relay Output Setup Start Screen
-- -
After you have set up this Relay Output, you can go to another Output Setup Start screen, the Sensor
Setup Start screen, or return to the Main screens.
OUTR
1
9. Press
Setup Start screen, or press
System 450 Main screens.
Screen example shows the Relay Output Setup-Start screen for Output 1.
Setting up an Analog Output (OUTA
An analog output provides an analog signal to control
your application based on a fixed setpoint sensor
(Sn-1, Sn-2, or Sn-3).
Analog outputs provide an auto-selecting analog signal
that is proportional to the sensed input condition. The
System 450 analog output senses the impedance of
the controlled equipment's analog input circuit and
automatically delivers either a 0–10 VDC or 4–20 mA
signal to the controlled equipment.
